Wire Setup
Carefully read and review all safety instructions,
warnings and cautions contained in the
Operating & Safety Manual.
Main Zone
Main Zone
Sub-Zone
1
Separated Zone
A
Base Station Location
Chap. 1.1.4
Corners
Chap. 1.6.1, 2.2.1
Wire Direction & Distance
Chap. 2.1.2
min 3m
Leave 30cm
at starting
point
32cm from edge
40cm from wall
Min 3m after corner
Avoid
slopes
Max 20m
Anti
Clockwise
Obstacles Inside Lawn
Chap. 1.6.1, 2.2.1
Hard obstacle
Soft obstacle
Both wires under
same peg
w
w
Main Zone Main Zone Main Zone Main Zone
Sub-Zone
Sub-Zone
Main Zone
Seperated
Zone
Chap. 1.3, 2.3 Chap. 1.2.2, 2.2.2 Chap. 1.2.2 Chap. 1.2.1
Multiple Zones & Narrow Pass Finish
Connect the wire
W 1.2m 1.2m W 2m 2m W 5m W 5m
