6.Placethenotchedendofthenewmemorymoduletowardthecontactedgesideofthememoryslot,
andinsertthememorymoduleintothememoryslotatanangleofabout20degrees1.Pivotthe
memorymoduledownwarduntilitsnapsintoplace2.Ensurethatthememorymoduleisrmlyinstalled
inthememoryslotandcannotbemovedeasily.
Attention:Donottouchthecontactedgeofthememorymodule.Otherwisethememorymodule
mightbedamaged.
Note:Ifyouinstallonlyonememorymodule,installitintothebottomslot.
7.Reinstallthelargebottomcover12,andthentightenthescrews3.
8.Reinstallthebatterypack.See“Replacingthebatterypack”onpage65.
9.Turnthecomputeroveragain.Connecttheacpoweradapterandallcablestothecomputer.
Replacingtheharddiskdriveorsolid-statedrive
Beforeyoustart,printtheseinstructions.
Attention:Theharddiskdriveorsolid-statedriveisverysensitive.Incorrecthandlingcancausedamage
andpermanentlossofdata.Observethefollowingguidelines:
Chapter6.Replacingdevices73
