![Lenovo thinkpad t540p, 20be0098rt [95/182] Replacing a wireless wan card](/img/pdf.png)
Lenovo thinkpad t540p, 20be0098rt [95/182] Replacing a wireless wan card
![Lenovo thinkpad t540p, 20be0098rt [95/182] Replacing a wireless wan card](/views2/1172667/page95/bg5f.png)
10.ConnecttheantennacablestothewirelessLANcard.Ensurethatyouattachthegraycabletothemain
connectorandtheblackcabletotheauxiliaryconnectoronthewirelessLANcard.
11.Reinstallthesmallbottomcover1.Thentightenthescrew2.
12.Reinstallthebatterypack.See“Replacingthebatterypack”onpage65.
13.Turnthecomputeroveragain.Connecttheacpoweradapterandallcablestothecomputer.
ReplacingawirelessWANcard
Beforeyoustart,printtheseinstructions.
PrerequisitesforreplacingorinstallingthewirelessWANcard
DANGER
Duringelectricalstorms,donotconnectthecabletoordisconnectitfromthetelephoneoutlet
onthewall.
DANGER
Electriccurrentfrompower,telephone,andcommunicationcablesishazardous.Toavoidshock
hazard,disconnectthecablesbeforeopeningthecoverofthisslot.
Chapter6.Replacingdevices79
