9
Robomow S models
P There should be a distance between the Island Wire and the Perimeter
Wire:
) Maintain a minimum of 1.5 m (5 ft.) between the Island wire and
the Perimeter Wire.
) Maintain a minimum of 1.5 m (5 ft.) between wires of adjacent
islands.
CAUTION: Setting the Perimeter Wire Anti Clockwise around the
obstacle will cause mower to drive into the island.
P Complete bordering the island and return to the spot where you left the
lawn’s edge.
P The wires leading to the Island and from it should be parallel and
touching.
Therefore, peg both wires, to and from the island, together with the
same pegs.
Robomow will not recognize these two wires.
It will mow over them as if they do not exist.
Robomow will recognize the single blocking wire around the
Perimeter Island and will not enter this area.
P The minimum diameter of an Island should be 90 cm (3 ft.).
) If protected objects are grouped closely together, demarcate them
by a single, continuous, Perimeter Island.
) The minimum distance of the Perimeter Wire from the protected
area should be 32 cm (1 ft.).
Therefore, If protected objects are too close to the edge, leave
them out of the mowing area.
2.2.2 Setting a Narrow Pass
A pass connects two larger zones of the lawn. This pass may be narrow,
but it is wide enough to let Robomow drive through it.
The pass has to be at least 1.2 m (4 ft.) wide to allow Robomow to drive
through it.
Following the Perimeter Wire, Robomow drives between the Main Zone and
the Sub-Zone. But, while mowing each zone it does not cross over to the
other one.
P If the pass is wider than 2 m (6.5 ft.) – there is NO need for any special
setting of the Perimeter Wire. Just include both the pass and the Sub-
Zone in the area covered by the Perimeter Wire.
P If the pass is narrow: 1.2 – 2 m (4 to 6.5 ft.) -you have to set a special
Perimeter Wire configuration in order to lead Robomow in and out of
the pass.
A special Template is supplied with Robomow. It is folded on top of
the mower inside the box. You use this Template to set the Narrow
Pass.
This special setting of the Perimeter Wire will lead Robomow directly
into the Narrow Pass.
picture טיילפמטהלש.
P There should be a 40 cm (1.3 ft.) distance between the Perimeter Wire
and the pass entrance.
P Pause the process of Perimeter Wire setting in order to prepare the
entrance to the Narrow Pass.
P Lay the Template on the ground at the entrance to the Narrow
Pass:
) The
arrow points towards the entrance to the
Narrow Pass, in the direction of the Sub-Zone.
) Insert by hand (half-way in) 7 pegs into the 7 holes
numbered
1
–
7
.
P Lift the Template up so the pegs are left loosely stuck in the
ground.
P Lay the Perimeter Wire through the four right-side pegs numbered
1
–
4
) Hold the wire around each peg
1
,
2
,
3
,
4
while
driving the peg all the way into the ground.
) Leave pegs 5 – 7 standing half-way out. They will be
connected to the wire later.
P Continue laying the Perimeter Wire through the pass towards
the Sub-Zone:
) Straight line at a minimum distance of 45 cm (1.5 ft.) from
the pass right side edge.
) Pause at the end of the Pass in order to set the other end
of the Narrow Pass.
P There should be a 40 cm (1.3 ft.) distance between the Sub-
Zone Perimeter Wire and the pass exit.
P Turn the Template and lay it on the ground at the entrance to
the Sub-Zone:
) The
arrow points towards the Sub-Zone.
) Insert by hand (half-way in) 7 pegs into the 7 holes
numbered 1 – 7.
P Lift the Template up so the pegs are left loosely stuck in the
ground.
P Lay the Perimeter Wire through the three right side pegs
numbered 1 – 3
) Hold the wire around each peg 1, 2, 3 while driving the
peg all the way into the ground.
90
O
45
O
Perimeter Island - Min. 90 cm (3 ft.).
32 cm (1 ft.)
