D-Link DSL-504 [11/72] Standards compatability and compliance

DSL-504 ADSL Router User’s Guide

Standards Compatability and Compliance

The DSL-504 complies with or is compatible with the following standards as

recognized by their respective agencies.

 ITU G.994.1 (G.Hs Auto-handshake) compliant

 ITU G.992.1 (G.dmt Full-rate ADSL) compliant

 ITU G.992.2 (G.lite “Splitterless ADSL”) compliant

 ITU-T Rec. I.361 compliant

 ITU-T Rec. I.610 compliant

 Compatible with all T1.413 issue 2 (full rate DMT over analog POTS), and CO

DSLAM equipment

 RFC 1483 Multi-protocol over ATM “Bridged Ethernet” compliant

 RFC 2364 PPP over ATM compliant

 RFC 2516 PPP over Ethernet compliant

 RFC 1334 PPP Authentication Protocol compliant

 RFC 1994 Challenge Handshake Authentication Protocol compliant

 RFC 791 Internet Protocol compliant

 RFC 826 Address Resolution Protocol compliant

 RFC 950 Internet Control Message Protocol compliant

 RFC 1631 Net Address Translator compliant

 Supports RFC 2131 and RFC 2132 DHCP functions including: automatic

assignment of IP address, use of subnet mask and default gateway and

provision of DNS server address for all hosts

 IEEE 802.3 compliant

 IEEE 802.3u compliant

 IEEE 802.1d compliant

 Supports RIP v1 and RIP v2

 Supports Static Routing

 Supports ATM Forum UNI V3.1 PVC

 Minimum ATM cell forwarding rate: 640 Kbps

 Supports up to eight simultaneous ATM virtual connections
