DSL-504 ADSL Router User’s Guide

IP Concepts

This appendix describes some basic IP concepts, the TCP/IP addressing scheme

and show how to assign IP Addresses.

When setting up the Router, you must make sure it has a valid IP address. Even

if you will not use the WAN port (ADSL port), you should, at the very least, make

sure the Ethernet LAN port is assigned a valid IP address. This is required for

telnet, in-band SNMP management, and related functions such as “trap”

handling and TFTP firmware download.

IP Addresses

The Internet Protocol (IP) was designed for routing data between network sites

all over the world, and was later adapted for routing data between networks

within any site (often referred to as “subnetworks” or “subnets”). IP includes a

system by which a unique number can be assigned to each of the millions of

networks and each of the computers on those networks. Such a number is called

an IP address.

To make IP addresses easy to understand, the originators of IP adopted a system

of representation called “dotted decimal” or “dotted quad” notation. Below are

examples of IP addresses written in this format:

201.202.203.204 189.21.241.56 125.87.0.1

Each of the four values in an IP address is the ordinary decimal (base 10)

representation of a value that a computer can handle using eight “bits” (binary

digits — 1s and 0s). The dots are simply convenient visual separators.

Zeros are often used as placeholders in dotted decimal notation; 189.21.241.56

can therefore also appear as 189.021.241.056.

IP networks are divided into three classes on the basis of size. A full IP address

contains a network portion and a “host” (device) portion. The network and host

portions of the address are different lengths for different classes of networks, as

shown in the table below.
