DSL-504 ADSL Router User’s Guide

PVC

Use this field to assign the VPI and VCI values for the Router. These numbers

are given to you by your DSL service provider and must be entered in order to

establish the ADSL connection.

PPPoE Login

Use this field to assign a Login User Name and Password used for

authentication by your network service provider. Type in the user name and

password in their respective fields. You can use any combination of up to 64

characters (no spaces) in both fields.

The Authentication protocol used to confirm the identity of the user can be

chosen from the pull-down menu. The available protocols are chap (by default)

and pap.

The Connect on Demand pull-down menu toggles either enabled or disabled.

When this function is enabled the router will connect any workstation on your

LAN to the Internet upon request. If this function is disabled, it will be necessary

to access this menu and hit the Connect button each time you want to establish a

connection to the WAN or the Internet. Most users will probably want to enable

this feature.

If your network account is not billed according to the amount of time connected,

the Idle Time field should be left at the default value 0. This means that the

Router is always connected and able to connect on demand.

If your network account is billed according to the amount of time the Router is

actually connected to the Internet, enter an appropriate Idle Time value (in

seconds). This will disconnect the Router after the WAN connection has been idle

for the amount of time specified.

PPPoE Information

This field provides information regarding the status of the Router’s connection to

the WAN. The global IP Address for the Router should be assigned

automatically by the network service provider’s PPP server. The Connection

Status will read Disconnect until the Router has established the WAN

connection.

Connect to WAN

If you have enabled the Connect on Demand feature, the Router will have

established the WAN connection upon restarting.

If the Connect on Demand feature has been disabled, click the Connect button to

initiate the PPP connection via the ADSL WAN interface. The “handshake”

process will take a few seconds.

In the PPPoE or PPPoA Configuration widow, viewing the Connection Status

Connected, under PPPoE Information will indicate a valid connection. A valid

ADSL connection can also be confirmed by observing the LED indicators on the

front panel of the device.
