DSL-504 ADSL Router User’s Guide
it is important that you allow the entire file to load onto the device. Do not turn
off the Router while the flash memory is being updated. A warning will appear
during the upgrade reminding you not to power off the device.
When the new firmware has been successfully loaded a new window will inform
you of the upgrade and tell you that the Router has been restarted. Click OK to
proceed.
61
