DSL-504 ADSL Router User’s Guide
Chapter 6 LAN Setup – Discusses different options for IP addressing on your
LAN. Describes how to change the IP address of the LAN interface on the Router.
Chapter 7 Using the Console Manager- Describes how to use the console
manager and lists the most commonly used commands, including how to change
the password used to access the web-based manager.
Appendix A Technical Specifications – Lists the technical specifications of
the Router, including standards compliance.
Appendix B IP Concepts – A discussion of IP address assignment and subnets
for a private network.
Appendix C DSL-504 Firmware Upgrade Utility – Describes how to install
and use the firmware upgrade utility used with the Router.
vii
