Scoole SC HT HM1 2000 BE [11/44] Electric heater of convection type

Operation of SC HT HL1 series heaters

1. Switching on

Insert the plug of the power cord to the receptacle to connect the heater to the electric mains. The

"POWER" indicator on the control panel will light up. After that, press the "POWER" button.

2. Selection of heating power modes*

For selection of heating power mode, press the "SET" button three times to display the symbol of the last

set power. Using the button, select the necessary heating power. When the low heating

power is selected, "LO" symbol is displayed; when the medium heating power is selected, "P2" symbol

is displayed; and when the high heating power is selected, "HI" symbol is displayed.

* - except for 1000W models

" " or " "

ENGLISHElectric heater of convection type

3. Temperature setting

3.1. Temperature can be set in the range from +5 to +30°C with 1°C step.

3.2. The factory temperature setting of the comfortable mode is +24°C; the factory temperature setting

of the economic mode is +17 °C.

3.3. To change temperature of the comfortable mode, press the "SET" button once. The "NORMAL"

indicator of the comfortable mode on the control panel will flash. The display will show the flashing value

of the last set temperature. During flashing of the temperature value, press the button to

set the desired temperature.

3.4. To change temperature of the economic mode, press the "SET" button twice. The "ECONOMY"

indicator of the economic mode on the control panel will flash. The display will show the flashing value of

the last set temperature. During flashing of the temperature value, press the button to set

the desired temperature.

3.5. After setting of the desired temperature, the last set value will be stored and the current temperature

will be displayed.

" " or " "
