NOTE:

For improvement of the product quality, the design, specifications, and delivery set of the heater

can be modified by the manufacturer without preliminary notification

ENGLISHElectric heater of convection type

6. Installation

1. Open the original package and carefully take the appliance out.

2. Remove foam plastic seals from edges of the appliance and free it of

polyethylene.

3. Take 2 supporting legs from the heater package.

4. Turn over the appliance so that its lower part looks up.

5. Attach the supporting legs to the lower part of the appliance on the left

and right sides so that mounting holes are aligned with holes on the

appliance body (Fig.2).

6. Drive the mounting screws to the available holes applying a sufficient

force (Fig.2). Check security of attachment.

7. Turn the appliance to the right position and place it onto the even

horizontal surface strictly vertically.

The appliance is ready for operation!

Figure 2.

WARNING!

The appliance should be operated only with installed supporting legs. Operation of the heater

without the supporting legs is prohibited!

Connection to electric mains

1. The heater is designed for connection to 220V single-phase electric mains.

2. Prior to connection, make sure that parameters of the local electric mains meet the parameters

specified on the nameplate of the appliance.

3. During connection of the heater to the electric mains, it is necessary to observe the effective electric

safety rules.

4. The receptacle should be properly earthed. The receptacle should be designed for rated current not

less than 10A. The receptacle and plug should be always dry to avoid current leakage.
