INSTRUCTION MANUAL

Regularly check that the plug tightly fits the receptacle as follows: a) insert the plug into the receptacle;

b) switch the heater off in half an hour of operation and remove the plug from the receptacle; c) check by

hand whether the plug is hot. If the plug temperature exceeds 50°C, the receptacle should be replaced

by a qualified specialist to avoid damage, accidents, or fire as a result of poor electric contact.

7. Heater control

Heaters of SC HT HM1 series are equipped with a mechanical thermostat.

Heaters of SC HT HL1 series are equipped with a high-precision electronic thermostat with a LED-

display.

WARNING!

The receptacle should be designed for rated current not less than 10A, while the electric cable should

have wire section not less than 3x1.5 mm2 (for copper).

1. Two-key switch, with indication*

This switch is used for selection of the following modes of

heating power: "ECONOMY" (low power), "COMFORT"

(medium power), "EXPRESS" (high power).

2. Thermostat knob

This knob is used for setting of desired temperature in the

room.

* - Except for SC HT HM1 1000W, SC HT HM1 1000BE, and

SC HT HM1 1000G models, which have one heating power

and use one-key switch.

Operation of SC HT HM1 series convection heaters

1. Switching on

Insert the plug of the power cord to the receptacle to connect

the heater to the electric mains.

Figure 3.
