49Y6002 A3W9 4TB 7.2K 6Gbps NL SATA 3.5" G2HS HDD 14
00FN143 A5VH 4TB 7.2K 6Gbps NL SATA 3.5" G2HS 512e HDD 14
00FN173 A5VM 6TB 7.2K 6Gbps NL SATA 3.5" G2HS 512e HDD 14
3.5-inch hot-swap SSDs - Enterprise Performance 6 Gbps SATA
00YC340 AT9G S3710 400GB Enterprise Performance SATA HS 3.5" SSD 14
00YC345 AT9H S3710 800GB Enterprise Performance SATA HS 3.5" SSD 14
3.5-inch hot-swap SSDs - Enterprise 6 Gbps SATA
00AJ485 A56H S3700 400GB SATA 3.5" MLC HS Enterprise SSD 14
00AJ490 A56J S3700 800GB SATA 3.5" MLC HS Enterprise SSD 14
3.5-inch hot-swap SSDs - Enterprise Entry 6 Gbps SATA
00WG770 AT97 S3510 120GB Enterprise Entry SATA HS 3.5" SSD 14
00WG775 AT98 S3510 240GB Enterprise Entry SATA HS 3.5" SSD 14
00WG780 AT99 S3510 480GB Enterprise Entry SATA HS 3.5" SSD 14
3.5-inch hot-swap SSDs - Enterprise Value 6 Gbps SATA
00AJ435 A57F 120GB SATA 3.5" MLC HS Enterprise Value SSD 14
00AJ445 A57H 480GB SATA 3.5" MLC HS Enterprise Value SSD 14
00YC420 AT8Y 960GB Enterprise Entry SATA HS 3.5" SSD 14
Part
number
Feature
code
Description Maximum
supported
Table 12. Drive options for internal storage (Part 4: 3.5-inch simple-swap drives)
Part
number
Feature
code
Description Maximum
supported
3.5-inch simple-swap HDDs - 6 Gbps NL SATA
81Y9802 A22U 500GB 7.2K 6Gbps NL SATA 3.5" G2SS HDD 8
81Y9806 A22X 1TB 7.2K 6Gbps NL SATA 3.5" G2SS HDD 8
81Y9810 A22W 2TB 7.2K 6Gbps NL SATA 3.5" G2SS HDD 8
Internal backup units
The x3650 M5 server does not support internal tape drive options or other internal backup units. However,
it can be attached to the external tape drives using SAS or Fibre Channel connectivity (see Table 33).
Optical drives
The x3650 M5 server supports the optical drive options listed in Table 13. Storage dense models with 12x
3.5-inch or up to 24x 2.5-inch drive bays on the front do not support internal optical drive; a supported
external optical drive can used instead.
Table 13. Optical drives
Part
number
Feature
code
Description Maximum
supported
Standard models
where used
00AM066 A5KG Ultraslim 9.5mm SATA DVD-ROM 1 -
00AM067 A5KH Ultraslim 9.5mm SATA Multi Burner 1 -
Lenovo System x3650 M5 27
