Lenovo b5130, 80lk00jdrk [11/52] Function key combinations

Chapter 1. Getting to know your computer

Function key combinations

To use the function key combinations, press the Fn key , then press one of

the function keys .

B41-35/B41-30/N41-35/N41-30:

B51-35/B51-30/N51-35/N51-30:

The following is a brief introduction to the function key combinations.

Fn + Home:

Activate the pause function.

Fn + End:

Activate the break function.

Fn + PgUp:

Enable/disable the scroll lock.

Fn + PgDn:

Activate the insert function.

Insert PrtSc Delete

Home End

PgUp

PgDn

Pause Break ScrL k SysRq
