unplug the tool. Remove the dust bag from the tool.

Then remove the dust nozzle from the dust bag after

unlocking the dust nozzle by turning it slightly

counterclockwise. Empty the dust bag by tapping it

lightly.

After emptying the dust bag, install the dust nozzle on

the dust bag. Turn the dust nozzle slightly clockwise to

lock it in place. Then install the dust bag on the tool as

described in "Installing dust bag".

Fig.6

Installing paper dust bag

Fig.7

Place the paper dust bag on the paper dust bag holder

with its front side upward. Insert the front fixing

cardboard of the paper dust bag into the groove of the

paper dust bag holder.

Then press the upper part of the front fixing cardboard in

arrow direction to hook it onto the claws.

Fig.8

Insert the notch of the paper dust bag into the guide of

the paper dust bag holder. Then install the paper dust

bag holder set on the tool.

Fig.9

Fig.10

Installing paper filter bag

Fig.11

Make sure that the logo on the cardboard lip and the

logo on the dust box are on the same side, then install

the paper filter bag by fitting the cardbord lip in the

groove of each holding tab.

Fig.12

Make sure that the logo on the cardboard lip and the

logo on the dust nozzle are on the same side, then

install the dust nozzle on the dust box.

Removing dust box and paper filter bag

Fig.13

Remove the dust nozzle by pushing the two latches.

Fig.14

Remove the paper filter bag first by pinching the logo

side of its cardboard lip, then by pulling the cardboard lip

downwards to move it out of the holding tab of the dust

box.

OPERATION

Sanding operation

Fig.15

CAUTION:

• Never switch on the tool when it is in contact with

the workpiece, it may cause an injury to operator.

• Never run the tool without the abrasive disc. You

may seriously damage the pad.

• Never force the tool. Excessive pressure may

decrease the sanding efficiency, damage the

abrasive disc or shorten tool life.

• Using the tool with the pad edge contacting the

workpiece may damage the pad.

Hold the tool firmly. Turn the tool on and wait until it

attains full speed. Then gently place the tool on the

workpiece surface. Keep the pad flush with the

workpiece and apply slight pressure on the tool.

CAUTION:

• The sanding pad rotates clockwise during the

loaded operation, but it may rotate

counterclockwise during the no-load operation.

MAINTENANCE

CAUTION:

• Always be sure that the tool is switched off and

unplugged before attempting to perform inspection

or maintenance.

To maintain product SAFETY and RELIABILITY, repairs,

carbon brush inspection and replacement, any other

maintenance or adjustment should be performed by

Makita Authorized Service Centers, always using Makita

replacement parts.

ACCESSORIES

CAUTION:

• These accessories or attachments are

recommended for use with your Makita tool

specified in this manual. The use of any other

accessories or attachments might present a risk of

injury to persons. Only use accessory or

attachment for its stated purpose.

If you need any assistance for more details regarding

these accessories, ask your local Makita Service Center.

• Abrasive discs

• Paper dust bag

• Paper dust bag holder

• Dust box

• Paper filter bag
