ENGLISH (Original instructions)
Explanation of general view
SPECIFICATIONS
• Due to our continuing programme of research and development, the specifications herein are subject to change without
notice.
• Specifications and battery cartridge may differ from country to country.
• Weight, with battery cartridge, according to EPTA-Procedure 01/2003
Intended use
ENE079-1
The tool is intended for impact drilling in brick, concrete
and stone. It is also suitable for screw driving and drilling
without impact in wood, metal, ceramic and plastic.
General Power Tool Safety
Warnings
GEA010-1
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and
instructions for future reference.
CORDLESS HAMMER DRIVER
DRILL SAFETY WARNINGS
GEB056-5
1. Wear ear protectors when impact drilling.
Exposure to noise can cause hearing loss.
2. Use auxiliary handle(s), if supplied with the tool.
Loss of control can cause personal injury.
3. Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring. Cutting
accessory contacting a “live” wire may make exposed
metal parts of the power tool “live” and could give the
operator an electric shock.
4. Hold power tool by insulated gripping surfaces,
when performing an operation where the fastener
may contact hidden wiring. Fasteners contacting a
“live” wire may make exposed metal parts of the
power tool “live” and could give the operator an
electric shock.
5. Always be sure you have a firm footing.
Be sure no one is below when using the tool in
high locations.
6. Hold the tool firmly.
7. Keep hands away from rotating parts.
8. Do not leave the tool running. Operate the tool
only when hand-held.
9. Do not touch the bit or the workpiece immediately
after operation; they may be extremely hot and
could burn your skin.
10. Some material contains chemicals which may be
toxic. Take caution to prevent dust inhalation and
skin contact. Follow material supplier safety data.
SAVE THESE INSTRUCTIONS.
WARNING:
DO NOT let comfort or familiarity with product (gained
from repeated use) replace strict adherence to safety
rules for the subject product. MISUSE or failure to
follow the safety rules stated in this instruction
manual may cause serious personal injury.
1. Battery cartridge
2. Button
3. Switch trigger
4. Lamp
5. Reversing switch lever
6. Speed change lever
7. Action mode changing ring
8. Arrow
9. Adjusting ring
10. Graduation
11. Sleeve
12. Blow-out bulb
13. Holster holder
14. Waist belt
Model HP330D
Capacities
Concrete 8 mm
Steel 10 mm
Wood 21 mm
Wood screw 5.1 mm x 63 mm
Machine screw M6
No load speed (min
-1
)
High (2) 0 - 1,500
Low (1) 0 - 400
Blows per minute (min
-1
)
High (2) 0 - 22,500
Low (1) 0 - 6,000
Overall length 201 mm
Net weight 1.1 kg
Rated voltage D.C. 10.8 V
Содержание
- Gr κρουστικό δραπανοκατσάβιδο οδηγίες χρήσης 1
- Hp330d 1
- Μπαταρίας 1
- Cordless hammer driver drill safety warnings 4
- English original instructions 4
- Explanation of general view 4
- General power tool safety warnings 4
- Save all warnings and instructions for future reference 4
- Save these instructions 4
- Specifications 4
- Battery protection system 5
- For battery cartridge 5
- Functional description 5
- Important safety instructions 5
- Installing or removing battery cartridge fig 1 5
- Save these instructions 5
- Switch action fig 2 5
- Tips for maintaining maximum battery life 5
- Turning on the front lamp fig 3 5
- Adjusting the fastening torque fig 7 6
- Assembly 6
- Blow out bulb optional accessory fig 10 6
- Drilling operation 6
- Hammer drilling operation 6
- Installing or removing driver bit or drill bit fig 8 6
- Operation fig 9 6
- Reversing switch action fig 4 6
- Selecting the action mode fig 6 6
- Speed change fig 5 6
- Maintenance 7
- Optional accessories 7
- Screwdriving operation 7
- Using holster optional accessory 7
- Using the tool as a hand screwdriver fig 11 7
- Algemene veiligheidswaarschuwingen voor elektrisch gereedschap 9
- Bewaar alle waarschuwingen en instructies om in de toekomst te kunnen raadplegen 9
- Nederlands originele instructies 9
- Technische gegevens 9
- Veiligheidswaarschuwingen specifiek voor een accuschroef boorhamermachine 9
- Verklaring van het onderdelenoverzicht 9
- Accubeveiligingssysteem 10
- Belangrijke veiligheidsinstructies 10
- Beschrijving van de functies 10
- Bewaar deze instructies 10
- De accu aanbrengen en verwijderen zie afb 1 10
- Tips voor een lange levensduur van de accu 10
- Voor accu s 10
- Aan uit schakelaars zie afb 2 11
- De lamp op de voorkant inschakelen zie afb 3 11
- De snelheid veranderen zie afb 5 11
- De werkingsfunctie kiezen zie afb 6 11
- Het draaikoppel instellen zie afb 7 11
- Werking van de omkeerschakelaar zie afb 4 11
- Bediening zie afb 9 12
- Blaasbalgje los verkrijgbaar zie afb 10 12
- Gebruik als boorhamer 12
- Gebruik als boormachine 12
- Gebruik als schroevendraaier 12
- Het schroefbit of boorbit aanbrengen en verwijderen zie afb 8 12
- Onderdelen aanbrengen verwijderen 12
- De holster gebruiken los verkrijgbaar 13
- Het gereedschap gebruiken als een handschroevendraaier zie afb 11 13
- Onderhoud 13
- Verkrijgbare accessoires 13
