INTRODUCTION

Your telescope is an excellent beginner’s

instrument, and is designed to observe

objects in the sky and also on land. It can

be your personal window on the universe or

allows you to intimately study the behavior of

nesting birds on a distant hillside.

The telescope is shipped with the following

parts:

• Optical tube

• Aluminum tripod with accessory tray

• Two 1.25” eyepieces: MA25mm, MA9mm

• 90 degree erect image diagonal mirror

• 2X Barlow

• Red-dot viewfinder with bracket

• Yoke-style mount

The Infinity 60 optical tube has a focal length

of 800mm, and its objective lens has a diam-

eter of 60mm.

The Infinity 70 optical tube has a focal length

of 700mm and diameter of 70mm.

The lens diameter is one of the most

important pieces of information about the

telescope. The size of the objective lens

determines how much detail you will be

able to see in your telescope. The focal

length information will help later on to

calculate magnification.

Setting up your telescope involves these

simple steps:

• Setting up your tripod

• Attach the accessory tray

• Attach the optical tube to the mount

• Attach the viewfinder

• Attach the diagonal mirror and eye-

piece

• Align the viewfinder

Study the picture on the next page and

become acquainted with the parts of

your telescope. Then proceed to “Set-

ting up your Tripod.”
