Hardware Setup

N150 and N300 Wireless Routers

Verify the Cabling

Verify that your router is cabled correctly and the cables are attached securely by checking

the router LEDs:

• The Power LED is lit solid green when the router is turned on.

• The WiFi LED

is lit solid green.

• The Internet LED

is lit solid green.

• The Ethernet LEDs (1 through 4)

are lit solid green or solid amber for any

computers cabled to the router by an Ethernet cable.

For information about troubleshooting with the LEDs, see Troubleshoot with the LEDs on

page 67.
