Nikon aculon a211 7x50 [6/22] Eyecups

Nomenclature

1 Eyecup

2 Neckstrap eyelet

3 Focusing ring

4 Objective lens

5 Interpupillary distance

6 Diopter ring

7 0 (zero) diopter position

8 Diopter index

9 Central shaft

!p Zoom lever (8-18x42, 10-22x50 only)

• Binoculars

• Eyepiececap

• Objectivelenscaps

• Softcase

• Neckstrap

• TripodadapterTRA-2(16x50,10-22x50only)

ITEMS SUPPLIED

Eyecups

For directions in which to turn the eyecups, please refer to the image on page 4.

Please refer to the numbered images on page 4.

Turn and slide type (7x35/8x42/10x42/7x50/10x50/12x50/16x50)

・For eyeglass wearers, use eyecups in the fully retracted position.

・For non-eyeglass wearers, use eyecups in the fully extended position.

Either way, to accurately adjust your view, you can use two click stops before reaching the fully extended/

retracted position.

Fold back type (8-18x42/10-22x50)

・For eyeglass wearers, fold back the end of the eyecups for use.

・For non-eyeglass wearers, do not fold back the end of the eyecups. Use them in the fully extended position.
