Olympus tough tg-850 ihs white [41/111] Using the setup menu
![Olympus tough tg-850 ihs white [41/111] Using the setup menu](/views2/1176201/page41/bg29.png)
41
EN
Using the setup menu
Press the button during shooting or playback to display the setup
menu.
The setup menu provides access to a variety of camera settings, such
as shooting and playback functions, time and date settings, and display
options.
1
Press the button.
• The setup menu is displayed.
MENU
Back
Interval Settings
Off
Settings Menu 2
World Time
LED Illuminator
TV Out
English
’14.02.26 12:30
X
2
Press H to select the page tabs. Use FG to select the
desired page tab and press I.
Off
MENU
BackSettings Menu 2
World Time
Interval Settings
LED Illuminator
TV Out
English
’14.02.26 12:30
X
Page tab
MENU
Back
Interval Settings
Off
Settings Menu 2
World Time
LED Illuminator
TV Out
English
’14.02.26 12:30
X
Submenu 1
3
Use FG to select the desired submenu 1 and then press the
A button.
MENU
Back
Interval Settings
Off
Settings Menu 2
World Time
LED Illuminator
TV Out
English
’14.02.26 12:30
X
Submenu 2
MENU
Back
Interval Settings
Settings Menu 2
World Time
LED Illuminator
TV Out
X
On
Off
4
Use
FG
to select the desired submenu 2
and then press the A button.
• Once a setting is selected, the display returns to
the Submenu 1.
• There may be additional operations.
MENU
Back
Interval Settings
On
Settings Menu 2
World Time
LED Illuminator
TV Out
English
’14.02.26 12:30
X
5
Press the button to complete the setting.
