51
EN
51
EN
For the operation method, refer to (P. 41).
Cropping image q [P]
Submenu 1 Submenu 2
Edit
P
1 Use
HI
to select an image, and press the A
button.
2 Use the zoom lever to select the size of the
cropping frame, and use
FGHI
to move the
frame.
3 Press the A button after you have selected the
area to trim.
• The edited image is saved as a separate
image.
Cropping frame
MENU
Back
Adding sound to still images q [R]
Submenu 1 Submenu 2
Edit
R
1 Use
HI
to select an image.
2 Aim the microphone toward the sound source.
3 Press the A button.
• Recording starts.
• The camera adds (records) sound for approx.
4 seconds while playing back the image.
Microphone
To play sound recordings
To play sound recorded with an image, select the image and press the A button.
• Press FG to adjust volume.
