Oregon Scientific bar218hg [5/13] Remote sensor

LOCATION

MEANING

Clock / alarm area Main unit batteries low

Outdoor temperature area Sensor batteries low

REMOTE SENSOR

The main unit can collect data from up to 5 sensors.

To set up the sensor:

1. Open the battery compartment.

2. Select a channel then press

RESET.

3. Close the battery door.

4. Place the sensor within 98 ft (30 m) of the main unit

using the table stand or wall mount.

TIP

Ideal placements for the sensor would be in any

location on the exterior of the home at a height of not

more than 5 ft (1.5 m) and which can shield it from

direct sunlight or wet conditions for an accurate reading.

1.5 m (5 ft)

NOTE

Use alkaline batteries for longer usage and

consumer grade lithium batteries in temperatures

below freezing.

SENSOR DATA TRANSMISSION

To search for a sensor:

Press and hold and MODE at a time.

The sensor reception icon in the remote sensor

area shows the status:

ICON DESCRIPTION

Main unit is searching for sensor(s).

A channel has been found.

The sensor cannot be found.

TIP

The transmission range may vary depending

on many factors. You may need to experiment with

various locations to get the best results.

CLOCK

MANUALLY SET CLOCK

1. Press and hold MODE.

2. Press

or to change the settings.

3. Press

MODE to conrm.
