Olympus vh-510, silver [11/79] Preparing the camera

Preparing the Camera

Inserting the battery and card

Battery/card

compartment cover

Battery/card compartment lock

Write-protect switch

Battery lock knob

Insert the battery as illustrated with the C mark

toward the battery lock knob.

Damage to the battery exterior (scratches, etc.) may

produce heat or an explosion.

Insert the battery while sliding the battery lock knob in

the direction of the arrow.

Insert the card straight until it clicks into place.

Turn off the camera before opening the battery/card

compartment cover.

When using the camera, be sure to close and lock

the battery/card compartment cover.

Slide the battery lock knob in the direction of the

arrow to unlock, and then remove the battery.

Always use SD/SDHC/SDXC cards or Eye-Fi card

with this camera. Do not insert other types of memory

cards. “Using the card” (p. 64)

Do not touch the contact area of the card directly.

This camera can be used without a card by storing

images in its internal memory.

“Number of storable pictures (still images)/Continuous

recording length (movies) in the internal memory and

cards” (p. 65, 66)
