![Qnap ts-431 Инструкция по эксплуатации онлайн [56/344] 162186](/views2/1178032/page56/bg38.png)
56
Settings
Configure the following settings on this page: 1) Enable Temperature
Alarm: enable this option to set the temperature alarm. When the
hard disk temperature exceeds the specified threshold level, the
system will record an error message; and 2) Rapid and complete test
schedules: schedule a rapid or complete test here. The result of the
latest test can be viewed on the "Summary" page.
Click "APPLY to Selected HDD" to apply the settings configured on
this page only to the selected hard disk drive or "APPLY to All HDDs"
to all hard disk drives.
Managing Expansion Enclosures
Note:
The function or its content is only applicable to some models: TS-470 Pro,
TS-470, TS-670 Pro, TS-670, TS-870 Pro, TS-870, TS-870U-RP, TS-879 Pro, TS-
879U-RP, TS-1079 Pro, TS-1270U-RP, TS-1279U-RP, TS-1679U-RP, TS-EC879U-RP,
TS-EC1279U-RP, TS-EC1279U-SAS-RP, TS-EC1679U-RP, TS-EC1679U-SAS-RP, SS-
EC1279U-SAS-RP, SS-EC1879U-SAS-RP and SS-EC2479U-SAS-RP, TVS-471, TVS-
671, TVS-871, TVS-871U-RP, TVS-1271U-RP, TVS-463, TVS-663, TVS-863, TVS-
863+.
First click an expansion enclosure (REXP) under "System Component" to check its
general information. Refer to the following table for actions available to manage an
expansion enclosure:
Action
Description
Enclosure Info
Click this button to check on details of the chosen
enclosure, including the enclosure model, serial
number, firmware version, BUS type, CPU
temperature, system temperature, power status,
system fan speed and power fan speed.
Locate (under "Action")
Click this button and the chassis LEDs of the
selected expansion enclosure will blink for easy
identification.
Update firmware (under
"Action")
Click this button to update firmware for the chosen
enclosure.
