Rename enclosure (under

"Action")

Click this button to rename the chosen enclosure.

RAID Group

Click this button and select a RAID group to check

its details, including capacity, RAID group name,

RAID type and disk member.

Total Disk List

Click this button to show or filter for the disks. Set

the filter from the drop down list to show only hard

disks based on the enclosure or NAS they belong

to, model, type (HDD or SSD), BUS type, capacity,

used type (data, free, error, spare, cache, or none)

and status. Click "Refresh" to refresh the list.

Recovering Expansion Enclosures

Note:

The function or its content is only applicable to some models: TS-470 Pro,

TS-470, TS-670 Pro, TS-670, TS-870 Pro, TS-870, TS-870U-RP, TS-879 Pro, TS-

879U-RP, TS-1079 Pro, TS-1270U-RP, TS-1279U-RP, TS-1679U-RP, TS-EC879U-RP,

TS-EC1279U-RP, TS-EC1279U-SAS-RP, TS-EC1679U-RP, TS-EC1679U-SAS-RP, SS-

EC1279U-SAS-RP, SS-EC1879U-SAS-RP and SS-EC2479U-SAS-RP, TVS-471, TVS-

671, TVS-871, TVS-871U-RP, TVS-1271U-RP, TVS-463, TVS-663, TVS-863, TVS-

863+.

Click "Recover" on top right side of the window to recover volumes on an enclosure that

is accidentally disconnected (e.g. unscheduled shutdown or the SAS cable is

unplugged) from the NAS host. When this occurs, a broken chain symbol will be shown

in the Chassis View. The status of the affected storage pool will be shown as "Error"

and RAID group as "Not active".

To recover a disconnected expansion enclosure, follow the steps below:

1. Click "Recover" > "Recover Enclosure".

2. Make sure that the correct input port is used for the expansion enclosure and click

"OK".

3. Click "OK".

4. The disconnected expansion enclosure is recovered.

5. The affected storage pools and RAID groups are also recovered.
