1.3 Document Annotation
Annotations in this document
W arning:
This indicates the instructions must be strictly followed. Failure to do so
could result in injury to human body or death.
Caution:
This indicates the action may lead to disk clearance or loss OR failure to
follow the instructions could result in data damage, disk damage, or product
damage.
Important:
This indicates the information provided is important or related to legal
regulations.
