Qnap ts-253 pro-8g [52/344] Storage
![Qnap ts-253 pro-8g [52/344] Storage](/views2/1178032/page52/bg34.png)
52
4.2.2 Storage
Manage volumes, storage pools and hard disk drives, encrypt and decrypt file systems,
and configure cache acceleration with Storage Manager.
For details on the features, refer to the following links:
Disks
Volumes
Storage Pools
Cache Acceleration
Note:
Some of the features listed above are applicable to certain models. Please
check for applicable models first as you review descriptions of the features.
53
59
73
76
