247
Note:
If the OpenVPN client is running on Windows 7, add the firewall rules in the
advanced settings of OpenVPN.
OpenVPN on Linux
1. Download OpenVPN from http://openvpn.net/index.php/open-source/downloads.htm
2. Install OpenVPN client on Linux.
3. Download OpenVPN configuration file and certificate from the NAS ("Applications" >
"VPN Service" > "VPN Server Settings" > "OpenVPN Settings").
4. Edit openvpn.ovpn and replace "OPENVPN_SERVER_IP" with OpenVPN server IP.
5. Put "ca.crt" and "openvpn.ovpn" into the configuration folder under OpenVPN
configuration subdirectory.
6. Run OpenVPN.
OpenVPN on Mac
1. Download the disk image of OpenVPN client from http://code.google.com/p/
tunnelblick/
2. Launch Tunnelblick.
3. Download OpenVPN configuration file and certificate from the NAS ("Applications" >
"VPN Service" > "VPN Server Settings" > "OpenVPN Settings").
4. Edit openvpn.ovpn and replace OPENVPN_SERVER_IP (alfred.myqnapnas.com) with
OpenVPN server IP.
5. Put "ca.crt" and "openvpn.ovpn" into the configuration folder under OpenVPN
configuration subdirectory.
6. Run OpenVPN.
