Smeg STC75 [16/35] User instructions
![Smeg STC75 [16/35] User instructions](/views2/1017908/page16/bg10.png)
User instructions
49
DELAYING THE PROGRAM (available in all programs except the
soak program)
The PROGRAM DELAY button (10) can be pressed to delay the start of
the program by up to 9 hours. This means that the dishwasher can be
operated at the time of day of your choice. Press the button several
times in succession and the display will show the delay with which the
appliance will start, beginning from 9 hours. The dishwasher will perform
a dish pre-washing, and when finish, the “delay program” will enter in
function as it was first set.
TO SAVE ON ENERGY! … AND PROTECT THE ENVIRONMENT
x Always try to run the dishwasher fully loaded.
x Do not wash the dishes in running water.
x Use the washing program that is most appropriate for each type of
load.
x Do not carry out any preliminary rinsing.
x If available, connect the dishwasher to a hot water supply up to 60°C.
TO CUT DOWN ON DETERGENT CONSUMPTION! … AND PROTECT
THE ENVIRONMENT
The phosphates contained in dishwasher detergents are harmful to the
environment. To avoid using excessive amounts of detergent and to save
on electricity, observe the following:
x separate the more delicate items from dishes that are more resistant
to aggressive detergents and high temperatures;
x do not pour the detergent directly on the dishes.
