User instructions
29
CUTLERY BASKET
The cutlery should be arranged in an orderly manner inside the basket, with the handles pointing
downwards. Take care during loading to avoid injury from the knife blades.
The basket is suitable for all types of cutlery, except those long enough to interfere with the upper
spray arm.
Ladles, wooden spoons and cooking knives can be placed in the upper basket,
making sure that
the knife blades do not protrude from the basket.
The cutlery basket features an
exclusive system
of
independent sliding tip-up supports
,
offering a choice of possible combinations to allow optimum use of the space available.
Vertical
inserts
Movement required
to extract the inserts
UPPER BASKET
It is recommended to load the upper basket with small- or medium-sized items such as glasses,
small plates, tea or coffee cups, shallow bowls and light objects made from heat resistant plastic. If
the upper basket is used in the lowermost position, it can also be loaded with serving dishes,
provided they are only slightly soiled.
The basket is equipped with two tip-up cutlery supports which can be raised or lowered as
required. See illustrations below.
Horizontal
insert
closed
Horizontal
insert
open
