Smeg PLA4645X7 [5/31] User instructions
![Smeg PLA4645X7 [5/31] User instructions](/views2/1017958/page5/bg5.png)
User instructions
TABLE FOR CERTIFICATION BODIES
Reference standard EN 50242
Reference program ECO
Load 10 place-settings
Type of detergent B
Amount of detergent 25 g
Rinse aid setting Depending on the model 3/4 or 4/6
1.3 Washing programs
The dishwasher is equipped with a control panel and an
INFORMATION
DISPLAY (8)
from which it is possible to carry out all the power switch-
on, switch-off and programming operations.
Before starting a washing program make sure that:
• The water supply tap is
open.
• The
correct amount of detergent
has been added to the
dispenser
.
• The baskets have been
correctly loaded.
• The spray arms are able to
rotate freely
and without
obstruction.
• The dishwasher door is
securely closed
.
LIGHTING
Pressing the
ON/OFF
button
(1)
will start the dishwasher and will lit up
the dishwasher pilot light
(6)
. After approximately
3 second
from this
operation the
DISPLAY (8)
will be turned on with a visualization that will
depend upon the state of the dishwasher.
