Instructions for the User

8. THE CONTROL PANEL

All the appliance's control and monitoring devices are placed together on the front panel. The table

below provides the key to the symbols used.

TOP RANGE

BQ61T

BQ6130T

BQ91T

"SMOKER" TRAY CENTRAL BURNER IGNITION KNOB

LEFT BURNER IGNITION KNOB RADIANT BURNER IGNITION KNOB

RIGHT BURNER IGNITION KNOB AUXILIARY BURNER IGNITION KNOB

RAPID BURNER IGNITION KNOB
