Smeg BQ6130T [7/22] Getting to know your appliance

Instructions for the User

5. GETTING TO KNOW YOUR APPLIANCE

BQ61T

BQ6130T

BQ91T

CONTROL PANEL

SMOKER

DRIP TRAY

HEAT DISPERSAL

VENTS

HOLES FOR LIGHTING

THE RIGHT AND LEFT

BURNERS BY HAND

GRIDS

CERAMIC PLATES

(UNDERNEATH THE

GRIDS)

RADIANT GRILL

BURNER

GLASS LID

THERMOMETER FOR

TEMPERATURE WITH

LID CLOSED

ROTISSERIE MOTOR

AUXILIARY BURNER

RAPID BURNER

BURNER GRID
