SPECIFICATIONS
Motor 4 V DC
Switch Single Speed/Reversible
No load Speed 180 r/min.(RPM)
Clutch 12 Positions
Torque 5 Nm max
Collet 6.35 mm
Weight (included battery) 0.47 kg
Charger Rating Input: 240V, 50Hz, AC only
Output: 5.6V-DC 140mA
Charge Time 10-12 hours
DESCRIPTION
1. Quick change chuck
2. LED worklight
3. Direction of rotation selector ( forward/reverse/
center lock)
4. Switch Trigger
5. Grip zone
6. Charger
7. Red charge light
8. Input jack
9. Charger plug
10. To decrease torque
11. To increase torque
12. Torque adjustment ring
13. Reverse
14. Forward
15. Collet
16. Bit
OPERATION
WARNING:
Do not allow familiarity with products to make you
careless. Remember that a careless fraction of a
second is sufficient to inflict serious injury.
WARNING:
Always wear safety goggles or safety glasses with
side shields when operating products. Failure to
do so could result in objects being thrown into
your eyes, resulting in possible serious injury.
WARNING:
Do not use any attachments or accessories
not recommended by the manufacturer of this
product. The use of attachments or accessories
not recommended can result in serious personal
injury.
APPLICATIONS
You may use this product for the purposes listed below:
n Driving screws with screwdriver bits
n Light-duty drilling
TO CHARGE
See Figure 2.
When charging the screwdriver, a red charge light will
illuminate on the handle of the screwdriver. This red charge
light will go off when the screwdriver is fully charged.
n Insert charger plug into input jack making sure it is
properly connect ed.
n Charger can be used with normal household voltage
of 240 V, 50Hz, AC only.
n Connect charger to power supply.
n After normal usage, a minimum of  hours charging
time is required to fully recharge the screwdriver.
n Do not place charger in an area of extreme heat or
cold. It will work best at normal room temperature.
n Remove the product from the charger once it is fully
charged and ready for use.
WARNING:
Battery products are always in operating condition.
Therefore, the switch should always be locked
when not in use or carrying at your side.
ADJUSTABLE TORQUE CLUTCH
This screwdriver is equipped with an adjustable torque
clutch for driving different types of screws into different ma-
te ri als. The proper setting depends on the type of ma te ri al
and the size of screw you are using.
ADJUSTING TORQUE
See Figure 3.
There are twelve torque indicator settings located on the
front of the screwdriver.
n Rotate adjustment ring to desired setting, aligning
num ber on adjustment ring with arrow on housing.
• 1 - 2 For driving small screws
• 3 - 4 For driving screws into soft material
• 5 - 7 For driving screws into soft and hard
materials
• 8 - 9 For driving screws into hard wood
• 10 - 11 For driving large screws
•
For full power applications
3
961067060-01(B).indd 3961067060-01(B).indd 3 8/11/08 3:11:28 PM8/11/08 3:11:28 PM
