4
OPERATION
DIRECTION OF ROTATION SELECTOR
(FORWARD/REVERSE/CENTER LOCK)
See Figure 4.
The direction of bit rotation is reversible and is controlled
by a selector located abo
ve the switch trigger. With the
screwdriver held in normal operating position, the direction
of rotation selector should be positioned to the left of the
switch trigger for forward motion. The direction is reversed
when the selector is to the right of the switch trigger.
Setting the switch trigger in the OFF (center lock) position
helps reduce the possibility of accidental starting when
not in use.
To stop the screwdriver, release the switch trigger and allow
the collet to come to a complete stop.
QUICK CHANGE CHUCK
See Figure 5.
A quick change chuck mounted on the screwdriver, is easy
for inser
ting or removing the bits. To insert a bit, insert the
bit into collet till lock. To remove a bit, simply pull the sleeve
of collet forward.
SPINDLE LOCK
The screwdriver spindle is locked when the On/Off switch
is not pressed.
This enables screws to be screwed in, even when the
battery is empty.
GRIP ZONE
Soft grip reduces the danger of slipping and thereby improves
the grip on the tool and handing.
At the same time, The rubber coating acheives a vibration-
reducing effect.
LED WORKLIGHT
See Figure 6.
The screwdriver has a built-in LED worklight. This feature is
convenient when working in close or tight areas where
additional light is needed. Whenever the switch trigger is
depressed, the LED worklight will illuminate.
NOTE: Dur
ing normal operation, if the LED w
orklight will not
illuminate, charge the screwdriver.
MAINTENANCE
WARNING:
When servicing, use only identical replacement
parts. Use of any other parts may create a hazard
or cause product damage.
WARNING:
Always wear safety goggles or safety glasses with
side shields during product operation or when
blowing dust. If operation is dusty, also wear a
dust mask.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use. Use
clean cloths to remove dirt, dust, oil, grease, etc.
WARNING:
Do not at any time let brake fluids, gasoline,
petroleum-based products, penetrating oils, etc.,
come in contact with plastic parts. Chemicals can
damage, weaken or destroy plastic which may
result in serious personal injury.
Do not open the battery yourself. There is a danger of
short circuit.
Only the parts shown on the parts list are intended to be
repaired or replaced by the customer. All other parts should
be replaced at an Authorized Service Center.
ENVIRONMENTAL PROTECTION
Recycle raw materials instead of disposing
as waste. The machine, accessories and
packaging should be sorted for
environmental-friendly recycling.
961067060-01(B).indd 4961067060-01(B).indd 4 8/11/08 3:11:30 PM8/11/08 3:11:30 PM
