SUPER

USER’S MANUAL

Revision 1.0b

SUPERSERVER

5015A-PHF

Содержание

Manual revision 1 b release date march 27 2013 2
Printed in the united states of america 2
Warning handling of lead solder materials used in this product may expose you to lead a chemical known to the state of california to cause birth defects and other repro ductive harm 2
About this manual 3
Manual organization 3
Preface 3
Chapter 1 introduction 6
Chapter 2 server installation 6
Chapter 3 system interface 6
Table of contents 6
Chapter 4 standardized warning statements for ac systems 7
Chapter 5 advanced motherboard setup 7
Appendix a post error beep codes 9
Appendix b system speciﬁ cations 9
Chapter 6 advanced chassis setup 9
Chapter 7 bios 9
1 overview 11
Chapter 1 11
Introduction 11
2 motherboard features 12
Memory 12
Onboard controllers ports 12
Onboard sata 12
Other features 12
Pci expansion slots 12
Processor 12
Chapter 1 introduction 13
Figure 1 1 intel ich9r chipset system block diagram 13
Intel atom 13
Intel ich9r 13
Lpc i o 13
Note this is a general block diagram please see chapter 5 for details 13
Pci e x16 13
3 server chassis features 14
Control panel 14
Expansions cards 14
Rear i o panel 14
Sata subsystem 14
System power 14
4 contacting supermicro 15
Asia paciﬁ c 15
Europe 15
Headquarters 15
1 overview 17
2 unpacking the system 17
3 preparing for setup 17
Chapter 2 17
Choosing a setup location 17
Server installation 17
4 warnings and precautions 18
Rack precautions 18
Server precautions 18
Ambient operating temperature 19
Circuit overloading 19
Mechanical loading 19
Rack mounting considerations 19
Reduced airﬂ ow 19
Reliable ground 19
4 rack mounting instructions 20
Installing into a telco rack 21
5 checking the motherboard setup 22
6 checking the drive bay setup 24
1 overview 25
2 control panel buttons 25
3 control panel leds 25
Chapter 3 25
Reset button 25
System interface 25
Overheat 26
1 about standardized warning statements 29
Chapter 4 29
Standardized warning statements for ac systems 29
Warning deﬁ nition 29
ןה תואבה תורהצהא ינפמ שמתשמה תא ריהזהל תנמ לע היישעתה ינקת יפ לע תורהז הלבח ןה תואבה תורהצהא ינפמ שמתשמה תא ריהזהל תנמ לע היישעתה ינקת יפ לע תורהז הלבח ה וא תולאש שיו הדימב תירשפא תיזיפי יהשלכ היעבב תולקתרוציל שי הכימת תקלחמ םע רשק רידגהל וא ןיקתהל םיאשר דבלב םיכמסומ םיאנכט ורקימרפוס לש תינכט תאה םיביכר אורקל שי ורקימרפוס יזראמב םיביכרה תרדגה וא תנקתה ינפל ואולמב חפסנה תא 30
ןונקת תורהצהאהרהז 30
ﻲﻓ ﻚﻧﺍ ﻥﺃ ﻦﻜﻤﻳ ﺔﻟﺎﺣ ﻲﻓ ﺐﺒﺴﺘﺗ ﺔﺑﺎﺻﺍ ﺔﻳﺪﺴﺟ ﺰﻣﺮﻟﺍ ﺍﺬﻫ ﻲﻨﻌﻳ ﺮﻄﺧ ﺮﻳﺬﺤﺗ ﻥﺃ ﻞﺒﻗ ﻱﺃ ﻰﻠﻋ ﻞﻤﻌﺗ ﺕﺍﺪﻌﻣ ﻛﻢﻠﻋ ﻰﻠﻋ ﻦ ﻦﻋ ﺔﻤﺟﺎﻨﻟﺍ ﺮﻁﺎﺨﻤﻟﺎﺑ ﺮﺋﺍﻭﺪﻟﺍ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﻛﻭﺔﻳﺍﺭﺩ ﻰﻠﻋ ﻦ ﺭﺎﻤﻤﻟﺎﺑﺕﺎﺳ ﺔﻴﺋﺎﻗﻮﻟﺍ ﻟ ﻊﻨﻤﻉﻮﻗﻭ ﻱﺃﺙﺩﺍﻮﺣ ﻢﻗﺭ ﻡﺪﺨﺘﺳﺍ ﻥﺎﻴﺒﻟﺍ ﺹﻮﺼﻨﻤﻟﺍ ﺔﻳﺎﻬﻧ ﻲﻓ ﺮﻳﺬﺤﺗ ﻞﻛ ﺭﻮﺜﻌﻠﻟ ﺎﻬﺘﻤﺟﺮﺗ 31
Installation instructions 32
אורקל שי רוקמל תכרעמה רוביח ינפל הנקתה תוארוה תאחתמ אורקל שי רוקמל תכרעמה רוביח ינפל הנקתה תוארוה תאחתמ 32
ﻟﺍ ﺕﺍﺩﺎﺷﺭﺇ ﺮﻗﺍﺐﻴﻛﺮﺘ ﻞﻴﺻﻮﺗ ﻞﺒﻗ ﻰﻟﺇ ﻡﺎﻈﻨﻟﺍ ﺔﻗﺎﻄﻠﻟ ﺭﺪﺼﻣ 32
Circuit breaker 33
V 20 a 33
לע ךמתסמ הז רצומנגהה תעינמל םינבמב תנקתומה יכ אדוול שי ילמשח רצק רצקה ינפמ ןגמה רישכמה ילמשחהמ רתוי אל אוה 33
ﺞﺘﻨﻤﻟﺍ ﺍﺬﻫ ﻰﻠﻋ ﺪﻤﺘﻌﻳ ﺕﺍﺪﻌﻣ ﺔﻳﺎﻤﺤﻟﺍ ﺓﺮﻴﺼﻘﻟﺍﺮﺋﺍﻭﺪﻟﺍ ﻦﻣ ﺎﻬﺘﻴﺒﺜﺗ ﻢﺗ ﻲﺘﻟﺍ ﻲﻓ ﻰﻨﺒﻤﻟﺍ 33
ﻦﻣ ﺪﻛﺄﺗ ﻥﺃ ﻢﻴﻴﻘﺗ ﺯﺎﻬﺠﻟﺍ ﻟﺍﻲﺋﺎﻗﻮ ﺲﻴﻟ ﻦﻣ ﺮﺜﻛﺃ 33
Power disconnection warning 34
הרהזא 35
ילמשח קותינ ינפמ הרהזא 35
למשחה תורוקמ לכמ תכרעמה תא קתנל שי ריסהל שיו קפסהמ ילמשחה לבכ תא נקתה ךרוצל זראמה לש ימינפה קלחל השיג ינפלת רסה ואת םיביכר 35
ﻞﺼﻓ ﺐﺠﻳ ﻡﺎﻈﻨﻟﺍ ﻊﻴﻤﺟ ﻦﻣﺭﺩﺎﺼﻣ ﺔﻗﺎﻄﻟﺍ ﺔﻟﺍﺯﺇﻭ ءﺎﺑﺮﻬﻜﻟﺍ ﻚﻠﺳ ﻦﻣ ﺓﺪﺣﻭ ﺩﺍﺪﻣﺍ ﺔﻗﺎﻄﻟﺍ ﻞﺒﻗ ﻰﻟﺇ ﻝﻮﺻﻮﻟﺍ ﺔﻴﻠﺧﺍﺪﻟﺍ ﻖﻁﺎﻨﻤﻟﺍ ﻟﻞﻜﻴﻬﻠ ﺔﻟﺍﺯﺇ ﻭﺃ ﺖﻴﺒﺜﺘﻟ ﺕﺎﻧﻮﻜﻣ ﺯﺎﻬﺠﻟﺍ 35
Equipment installation 36
הרהזא שר דבלב ךמסומ תווצתא ףילחהל ןיקתהל יא דויצה רובע תוריש תתל וא דויצה 36
ﻦﻴﺑﺭﺪﻤﻟﺍﻭ ﻭ ﺐﻴﻛﺮﺘﻟﻝﺍﺪﺒﺘﺳﺍ ﻭﺃ ﺔﻣﺪﺧ ﺯﺎﻬﺠﻟﺍ ﺍﺬﻫ ﺢﻤﺴﻳ ﻥﺃ ﺐﺠﻳ ﻂﻘﻓ ﻦﻴﻠﻫﺆﻤﻟﺍ ﻦﻴﻔﻅﻮﻤﻠﻟ 36
Restricted area 37
Battery handling 38
הרהזא 38
תלבגומ השיג םע רוזא 38
תרזעב תנתינ השיגה השיג תלבגה םהב שיש םירוזאב הדיחיה תא ןיקתהל שי דכו לוענמ חתפמ דבלב החטבא ילכ 38
ﺺﻴﺼﺨﺗ ﺓﺪﺣﻮﻟﺍ ﻩﺬﻫ ﻲﻓ ﺎﻬﺒﻴﻛﺮﺘﻟ ﻖﻁﺎﻨﻣ ﺓﺭﻮﻈﺤﻣ ﻢﺗ ﺻﻮﻟﺍ ﻦﻜﻤﻳﻰﻟﺇ ﻝﻮ ﺔﻘﻄﻨﻣ ﺓﺭﻮﻈﺤﻣ ﻂﻘﻓ ﻡﺍﺪﺨﺘﺳﺍ ﻝﻼﺧ ﻦﻣ ﺔﺻﺎﺧ ﺓﺍﺩﺃ ﻭﺃ ﻱﺃ ﻼﻟ ﻯﺮﺧﺃ ﺔﻠﻴﺳﻭﻥﺎﻣﻷ ﺡﺎﺘﻔﻣﻭ ﻞﻔﻗ 38
הרהזא 39
תנכס תמייקץוציפ הניקת אל ךרדב הפלחוהו הדימב הללוסה לש ףילחהל שי גוסב הללוסה תא מ םאותה תרבחלמומ ןרציתצ תוללוסה קוליס תושמושמה עצבל שי ןרציה תוארוה יפל 39
ﺮﻄﺧ ﻙﺎﻨﻫ ﻦﻣ ﻝﺍﺪﺒﺘﺳﺍ ﺔﻟﺎﺣ ﻲﻓ ﺭﺎﺠﻔﻧﺍ ﺔﻳﺭﺎﻄﺒﻟﺍ ﺔﺤﻴﺤﺻ ﺮﻴﻏ ﺔﻘﻳﺮﻄﺑ ﻚﻴﻠﻌﻓ ﺔﻳﺭﺎﻄﺒﻟﺍ ﻝﺍﺪﺒﺘﺳﺍ ﻂﻘﻓ ﻉﻮﻨﻟﺍ ﺲﻔﻨﺑ ﺎﻬﻟﺩﺎﻌﻳ ﺎﻣ ﻭﺃ ﺎﻤﻛﺖﺻﻭﺃ ﺔﻌﻨﺼﻤﻟﺍ ﺔﻛﺮﺸﻟﺍ ﻪﺑ ﺕﺎﻳﺭﺎﻄﺒﻟﺍ ﻦﻣ ﺺﻠﺨﺗ ﻟ ﺎﻘﻓﻭ ﺔﻠﻤﻌﺘﺴﻤﻟﺍﺔﻌﻧﺎﺼﻟﺍ ﺔﻛﺮﺸﻟﺍ ﺕﺎﻤﻴﻠﻌﺘ 39
Redundant power supplies 40
דחא קפסמ רתוי םייק םא 40
הרהזא 40
קפס לש דחא רוביחמ רתוי שי הדחיל תא ריסהל שיןקורל תנמ לע םירוביחה לכ חיה תאי הד 40
Backplane voltage 41
ﺪﻗ ﺍﺬﻬﻟ ﻥﻮﻜﻳ ﻟﺍﺯﺎﻬﺠ ﺕﻻﺎﺼﺗﺍ ﺓﺪﻋ ﺕﺍﺪﺣﻮﺑ ﺔﻗﺎﻄﻟﺍ ﺩﺍﺪﻣﺍ ﺔﻟﺍﺯﺇ ﺐﺠﻳ ﺕﻻﺎﺼﺗﻻﺍ ﺔﻓﺎﻛ ﻝﺰﻌﻟ ﻟﺍﺓﺪﺣﻮ ﻦﻋ ءﺎﺑﺮﻬﻜﻟﺍ 41
Comply with local and national electrical codes 42
זא הרה זא הרה ךלהמב רהזיהל שי תכרעמה לועפת ןמזב ירוחאה לנפב חתמ תנכס תמייק הדובעה 42
ירוחאה לנפב חתמ 42
ﻙﺎﻨﻫ ﺮﻄﺧ ﻦﻣ ﻲﺋﺎﺑﺮﻬﻜﻟﺍ ﺭﺎﻴﺘﻟﺍ ﻰﻠﻋ ﺓﺩﻮﺟﻮﻤﻟﺍ ﺔﻗﺎﻄﻟﺍﻭﺃ ﺔﺣﻮﻠﻟﺍ ﻥﻮﻜﻳ ﺎﻣﺪﻨﻋﻡﺎﻈﻨﻟﺍ ﻞﻤﻌﻳ ﺪﻨﻋ ﺍﺭﺬﺣ ﻦﻛ ﺔﻣﺪﺧ ﺯﺎﻬﺠﻟﺍ ﺍﺬﻫ 42
Product disposal 43
הרהזא הרהזא תנקתה םייצראהו םיימוקמה למשחה יקוחל תמאות תויהל תבייח דויצה 43
יצראה למשחה יקוח םואית 43
ﺕﺍﺪﻌﻤﻟﺍ ﺐﻴﻛﺮﺗ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﻠﻟ ﻞﺜﺘﻤﻳ ﻥﺃ ﺐﺠﻳ ﻦﻴﻧﺍﻮﻘﺔﻴﻨﻁﻮﻟﺍﻭ ﺔﻴﻠﺤﻤﻟﺍ ﺔﻘﻠﻌﺘﻤﻟﺍ ءﺎﺑﺮﻬﻜﻟﺎﺑ 43
Hot swap fan warning 44
הרהזא הרהזא ו תויחנהל םאתהב תויהל בייח הז רצומ לש יפוס קוליס הנידמה יקוח 44
רצומה קוליס 44
ﻲﺋﺎﻬﻨﻟﺍ ﺺﻠﺨﺘﻟﺍ ﻦﻣ ﺞﺘﻨﻤﻟﺍ ﺍﺬﻫ ﻪﻌﻣ ﻞﻣﺎﻌﺘﻟﺍ ﻲﻐﺒﻨﻳ ﻟ ﺎﻘﻓﻭ ﻊﻴﻤﺠﺔﻴﻨﻁﻮﻟﺍ ﺢﺋﺍﻮﻠﻟﺍﻭ ﻦﻴﻧﺍﻮﻘﻟﺍ ﺪﻨﻋ 44
הרהזא יקלח תא םיריסמ רשאכ שי םידבוע ןיידע םיררוואמהו ןכתי זראמהמ ררוואמה קיחרהללררוואמה ךותב םיחתפהמ םינוש הדובע ילכו תועבצאה תא חוטב קחרמ 45
ﻦﻜﻤﻤﻟﺍ ﻦﻣ ﺡﻭﺍﺮﻤﻟﺍ ﻥﺃ ﻝﺍﺰﺗ ﻻ ﺔﻟﺍﺯﺇ ﺪﻨﻋﺭﻭﺪﺗ ﺔﻠﺘﻛ ﺔﺣﻭﺮﻤﻟﺍ ﻞﻜﻴﻬﻟﺍ ﻦﻣ ﺐﺠﻳ ءﺎﻘﺑﺇ ﻦﻜﻤﻤﻟﺍ ﻦﻣ ﺡﻭﺍﺮﻤﻟﺍ ﻥﺃ ﻝﺍﺰﺗ ﻻ ﺔﻟﺍﺯﺇ ﺪﻨﻋﺭﻭﺪﺗ ﺔﻠﺘﻛ ﺔﺣﻭﺮﻤﻟﺍ ﻞﻜﻴﻬﻟﺍ ﻦﻣ ﺐﺠﻳ ءﺎﻘﺑﺇ ﻊﺑﺎﺻﻷﺍ ﻭﻲﻏﺍﺮﺒﻟﺍ ﺕﺎﻜﻔﻣ ءﺎﻴﺷﻷﺍ ﻦﻣ ﺎﻫﺮﻴﻏﻭ ﺍﺪﻴﻌﺑ ﻦﻋ ﺕﺎﺤﺘﻔﻟﺍ ﻲﻓ ﺔﻠﺘﻛ ﺔﺣﻭﺮﻤﻟﺍ 45
Power cable and ac adapter 46
1 handling the motherboard 49
Advanced motherboard setup 49
Chapter 5 49
Precautions 49
2 motherboard installation 50
Unpacking 50
3 connecting cables 51
Connecting data cables 51
Connecting power cables 51
Connecting the control panel 51
4 i o ports 52
5 6 7 8 52
Erver 5015a phf user s manual 52
Figure 5 1 control panel header pins 52
Figure 5 2 below for the colors and locations of the various i o ports 52
Figure 5 2 i o ports 52
Keyboard 5 com1 52
Ps 2 mouse 6 vga port 52
Rear i o ports 52
The i o ports are color coded in conformance with the pc 99 speciﬁ cation see 52
Usb1 7 lan1 52
Usb2 8 lan2 52
5 onboard processor 53
6 installing memory 53
Caution 53
Dimm installation 53
Memory support 53
7 adding pci expansion cards 55
8 motherboard details 56
J10 j11 56
J14 jpf 56
9 connector deﬁ nitions 58
Adequate power to the processor 58
Connector at j8 is used to provide 58
Connector the 4 pin external power 58
Eps 12v speciﬁ cation see the table 58
Erver 5015a phf user s manual 58
External power connector 58
Hard disks cd rom drives this power connector supports 12v and 5v devices 58
In addition to the 24 pin main power 58
Main atx power supply connector 58
Momentarily contacting both pins 58
On the right for pin deﬁ nitions 58
Power button 58
Power to external devices such as 58
Processor power connector 58
Seconds refer to the table on the right for pin deﬁ nitions 58
The 24 pin main power connector jpw1 is used to provide power to the motherboard this power connec tor meets the ssi eps 12v speciﬁ ca tion see the table on the right for pin deﬁ nitions 58
The 4 pin processor power connec 58
The power button connection is located on pins 1 and 2 of jf1 58
This power connector meets the ssi 58
Tor j7 is also required to ensure 58
Will power on off the system to turn off the power when set to suspend mode press the button for at least 58
Advanced warning of chassis over 59
And ide 59
Cable to display network activity see 59
Chapter 5 advanced motherboard setup 59
Connect an led to pins 7 and 8 of 59
Deﬁ nitions 59
For pin deﬁ nitions 59
Hard drive led cable here to display disk activity for any hard drive activ ity on the system including sata 59
Hdd led 59
Heating refer to the table on the right 59
Jf1 to indicate fan fail and provide 59
Nic1 lan1 led 59
Nic2 lan2 led 59
On pins 11 and 12 of jf1 attach an led cable to display network activ ity see the table on the right for pin 59
Overheat fan fail 59
Pins 9 and 10 of jf1 attach an led 59
Power fail led 59
Reset button 59
The hdd led connection is located on pins 13 and 14 of jf1 attach a 59
The led connections for lan1 are 59
The led connections for lan2 are on 59
The power fail led connection is located on pins 5 and 6 of jf1 re fer to the table on the right for pin deﬁ nitions 59
The reset button from the computer chassis connects to pins 3 and 4 of jf1 see the table on the right for pin deﬁ nitions 59
The table on the right for pin deﬁ ni 59
Tions lan2 on 5015a h only 59
3 of the fan headers are backward 60
Agement via bios hardware moni 60
An led to provide warnings of chas sis overheat this led will also blink to indicate a fan failure refer to the 60
Are 4 pin fan headers however pins 60
Compatible with the traditional 3 pin 60
Default setting is disabled note 60
Erver 5015a phf user s manual 60
Fan headers 60
Fan1 is the cpu fan and fan2 is for 60
Fans are controlled by thermal man 60
Fans the speeds of 4 pin pwm 60
For pin deﬁ nitions 60
Nmi button 60
Overheat fan fail led joh 60
Please use all 3 pin fans or all 4 pin fans on a motherboard please do not use 3 pin fans and 4 pin fans on the 60
Power led 60
Same board 60
Table on right for pin deﬁ nitions 60
The joh header is used to connect 60
The non maskable interrupt button header is located on pins 19 and 20 of jf1 refer to the table on the right 60
The power led connector is located on pins 15 and 16 of jf1 this con nection is used to provide led indica tion of power being supplied to the system see the table on the right for pin deﬁ nitions 60
The system cooling fan these fans 60
The x7spa hf has two fan headers 60
Toring in the advanced setting the 60
A chassis intrusion header is located at jl1 on the motherboard attach the appropriate cable from the chassis to 61
C connector 61
C connector monitors the status 61
Chapter 5 advanced motherboard setup 61
Chassis intrusion 61
Devices 61
For pin deﬁ nitions 61
Front panel audio header 61
Inform you of a chassis intrusion when 61
Of the power supply fan and system temperature see the table on the right 61
On module dom solid state storage 61
Port and com2 is a header located behind the i o ports see the table on the right for pin deﬁ nitions 61
Power smb 61
Power system management bus 61
Sata dom power 61
Serial ports 61
The chassis is opened 61
The front panel audio header is used to connect the chassis front panel high deﬁ nition audio hda controls to the motherboard see the table on the right for pin deﬁ nitions 61
The sata dom power on jwf1 is 61
Two serial ports are included on the motherboard com1 is a backpanel 61
Used to supply power to sata disk 61
A 4 pin cd header is located at cd1 this header allows you to use the on board sound for audio cd playback connect an audio cable from your cd drive to the header that ﬁ ts your cable s connector see the table at right for pin deﬁ nitions 62
A system management bus smb header is located at jsmb connect the appropriate cable here to use 62
And lan2 are located beside the vga port on the i o backplane these ports accept rj45 type cables 62
Are used to communicate with the 62
Atx ps 2 keyboard and ps 2 mouse ports 62
C connection on your 62
Cd header 62
Enclosure management chip in the 62
Erver 5015a phf user s manual 62
For pin deﬁ nitions refer to the board 62
Headers 62
Lan1 2 ethernet ports 62
Layout below for the locations of the 62
Located near the sata connectors 62
Mouse are located beside the usb0 1 ports the mouse port is above the keyboard port see the table on the 62
On the motherboard these headers 62
Purpose input output headers are 62
Right for pin deﬁ nitions 62
System 62
System see the table on the right 62
T sgpio 0 1 headers 62
The atx ps 2 keyboard and the ps 2 62
The smb 62
Two ethernet ports designated lan1 62
Two t sgpio serial link general 62
An lvds connector j5 is available on the x7spa l only this connector provides 18 bit lvds low voltage differential signaling for an lcd panel or other similar devices refer to the table on the right for pin deﬁ ni tions 63
Backlight module of the lcd panel to 63
Chapter 5 advanced motherboard setup 63
Connector and is used in conjunction 63
For pin deﬁ nitions 63
Four universal serial bus ports 63
Headers usb5 6 7 8 9 are pro 63
Inverter power 63
Inverter power connector 63
Light lamp pwm control signals and 63
Lvds connector 63
The inverter connector on j6 is a 7 pin 63
This socket this controls the back 63
Universal serial bus usb 63
Usb1 2 3 4 are located on the i o backpanel additionally one type a usb port usb10 and ﬁ ve usb 63
Vided on the motherboard to provide front chassis access cables are not included see the tables on the right 63
With the lvds connector connect the 63
10 jumper settings 64
Agement controller bmc and ipmi this jumper is used together with the ipmi settings in the bios the default 66
Bmc enable disable 66
Com3 redirection select 66
Dcd p5v select 66
Erver 5015a phf user s manual 66
Fault setting is rs232 this is an oem 66
For a power led and pins 4 7 are 66
Hda ac97 select 66
Jl2 allows the user to select between high deﬁ nition audio hda or legacy ac97 audio the default setting is hd audio 66
Jpc3 allows selection between rs232 66
Jumpers j10 j13 allow selection between the standard data carrier detect dcd modem signal or the system voltage 5v on pin 1 of the com1 com4 ports this is an oem option only 66
On the jd1 header pins 1 3 are used 66
Option only 66
Or ttl for com3 redirection the de 66
Position is pins 1 and 2 to enable bmc see the table on the right for jumper settings 66
Should close pins 6 7 with a jumper see the table on the right for speaker pin deﬁ nitions 66
Speaker jumper 66
The jpb jumper is used to enable or disable the onboard baseboard man 66
Used for an external speaker if you 66
Wish to use the onboard speaker you 66
11 onboard indicators 67
12 sata ports 67
Ata these sata ports are supported by the intel ich9r 67
Chapter 5 advanced motherboard setup 67
Faster data transmission than 67
I sata 0 5 are located on 67
Lan1 2 leds 67
Rial link connections provide 67
Sata ports 67
Serial link connections se 67
Six serial ata sata ports 67
South bridge see the table on 67
The ethernet ports located beside the vga port have two leds on each port the yellow led indicates activity while the other led may be green amber or off to indicate the speed of the connection see the table on the right for the indication associated with the connection speed led 67
The motherboard to provide 67
The right for pin deﬁ nitions 67
Those of the traditional parallel 67
13 installing software 68
Superdoctor iii 69
13 onboard battery 70
1 static sensitive devices 71
Advanced chassis setup 71
Chapter 6 71
Precautions 71
Tools required 71
2 control panel 72
3 system fans 73
4 drive bay installation removal 73
Erver 5015a phf user s manual 74
Figure 6 3 installing a 3 hard drive 74
Figure 6 4 installing 2 hard drives 74
5 power supply 75
Erver 5015a phf user s manual 76
Figure 6 5 installing the power supply 76
1 introduction 77
Chapter 7 77
How to change the conﬁ guration data 77
Starting bios setup utility 77
2 main setup 78
How to start the setup utility 78
3 advanced setup conﬁ gurations 80
Boot feature 80
Cpu conﬁ guration 82
Warnin 82
Advanced chipset control 83
Northbridge conﬁ guration 83
Ide sata conﬁ guration 84
Pci pnp conﬁ guration 87
Remote access conﬁ guration 88
Super io device conﬁ guration 88
Conﬁ guration 90
Hardware health 90
Acpi conﬁ guration 92
Ipmi conﬁ guration x7spa hf only 94
Event log conﬁ guration 95
4 security settings 96
5 boot settings 98
Boot device priority 98
Hard disk drives 98
6 exit options 99
Removable drives 99
Appendix a 101
Post error beep codes 101
Recoverable post error beep codes 101
Appendix b 103
Chassis 103
Chipset 103
Hard drive support 103
Memory capacity 103
Motherboard 103
Pci expansion slots 103
Processors 103
Sata controller 103
System speciﬁ cations 103
Weight 103
Operating environment 104
Power supply 104
Regulatory compliance 104
System input requirements 104
Erver 5015a phf user s manual 106

Supermicro SYS-5015A-PHF Инструкция по эксплуатации онлайн

Содержание

Похожие устройства
