Chapter 4: AMI BIOS
4-9
QPI Frequency
Use this feature to select the desired QPI frequency. The options are Auto,
4.800 GT, 5.866GT, 6.400 GT.
QPI L0s and L1
Select Enabled to lower QPI power state. L0s and L1 are automatically selected
by the motherboard. The options are Disabled and Enabled.
Memory Frequency
This feature forces a DDR3 frequency slower than what the system has detected
to run at a certain speed. The available options are Auto, Force DDR-800, Force
DDR-1066, and Force DDR-1333.
Memory Mode
Select Independent to make all DIMMs available to the operating system. Select
Channel Mirroring to maintain two identical copies of all data in Channel 1 and
Channel 2 memory modules for data security. Select Lockstep for the mother-
board to use two areas of memory to run the same set of operations in parallel.
Select Sparing for a preset threshold of correctable errors to be used to trigger
fail-over. The spare memory is put online and used as active memory in place
of the failed memory. This option is supported by Intel 5600 Series processors
only. The options are Independent, Channel Mirroring, Lockstep, and Sparing.
Demand Scrubbing
This is a memory error-correction scheme that allows the processor to write cor-
rected data back into the memory block from where it was read by the processor.
The options are Enabled and Disabled.
Patrol Scrubbing
This is a memory error-correction scheme that works in the background looking
for and correcting resident errors. The options are Enabled and Disabled.
Throttling - Closed Loop
Throttling improves reliability and reduces power in the processor by automatic
voltage control during processor idle states. The options are Enabled and Dis-
abled.
NorthBridgeConguration
This feature is used to congure the settings for the Intel North Bridge chip.
