SUPERSERVER

5018D-MF

USER’S MANUAL

1.0a

Содержание

Manual revision 1 a release date march 18 2015 2
Printed in the united states of america 2
Warning handling of lead solder materials used in this product may expose you to lead a chemical known to the state of california to cause birth defects and other repro ductive harm 2
About this manual 3
Chapter 1 introduction 3
Chapter 2 server installation 3
Chapter 3 system interface 3
Chapter 4 standardized warning statements 3
Manual organization 3
Preface 3
Appendix a bios error beep codes 4
Appendix b system specifications 4
Chapter 5 advanced motherboard setup 4
Chapter 6 advanced chassis setup 4
Chapter 7 bios 4
Chapter 1 introduction 6
Chapter 2 server installation 6
Chapter 3 system interface 6
Table of contents 6
Chapter 4 standardized warning statements for ac systems 7
Chapter 5 advanced motherboard setup 7
Appendix a bios error beep codes 8
Appendix b system specifications 8
Chapter 6 advanced chassis setup 8
Chapter 7 bios 8
1 overview 9
Chapter 1 9
Introduction 9
2 motherboard features 10
I o ports 10
Memory 10
Processors 10
Serial ata 10
3 server chassis features 11
Control panel 11
Cooling system 11
Serial ata subsystem 11
System power 11
Ctrl fan speed 12
Debug card 12
Erver 5018d mf user s manual 12
Figure 1 1 intel c222 chipset 12
Front panel 12
Note this is a general block diagram please see chapter 5 for details 12
Note two chipsets are shown the c222 applies to the x10sll f 12
Pch lynx point c222 c224 12
System block diagram 12
System power 12
Up to 1600 12
Usb usb 12
4 contacting supermicro 13
1 overview 15
2 unpacking the system 15
3 preparing for setup 15
Chapter 2 15
Server installation 15
4 warnings and precautions 16
Choosing a setup location 16
Rack precautions 16
Server precautions 16
Ambient operating temperature 17
Circuit overloading 17
Mechanical loading 17
Rack mounting considerations 17
Reduced airflow 17
Reliable ground 17
5 installing the system into a rack 18
Basic installation procedure 18
Installing with rackmount kit 19
1 overview 23
2 control panel buttons 23
Chapter 3 23
System interface 23
3 control panel leds 24
Overheat fan fail 24
1 about standardized warning statements 27
Chapter 4 27
Standardized warning statements for ac systems 27
Warning definition 27
ןונקת תורהצהאהרהז ןה תואבה תורהצהא ינפמ שמתשמה תא ריהזהל תנמ לע היישעתה ינקת יפ לע תורהז הלבח ה וא תולאש שיו הדימב תירשפא תיזיפי יהשלכ היעבב תולקתרוציל שי הכימת תקלחמ םע רשק רידגהל וא ןיקתהל םיאשר דבלב םיכמסומ םיאנכט ורקימרפוס לש תינכט תאה םיביכר אורקל שי ורקימרפוס יזראמב םיביכרה תרדגה וא תנקתה ינפל ואולמב חפסנה תא 28
ف ك ا ىأ يكو ةلاح ف ببستت ةباصا ة ذسج زهزلا اذه ع زطخ ز ذحت ىأ لبق يأ ىلع لوعت تاذعه كنلع ىلع ي يع ةوجا لا زطاخولاب زئاوذلا ة ئابزهكلا كوة ارد ىلع ي راوولابتاس ة ئاقىلا ل ع وعىقو يأثداىح نقر مذختسا ىا بلا صىص ولا ة اه ف ز ذحت لك رىثعلل اهتوجزت 29
Installation instructions 30
אורקל שי רוקמל תכרעמה רוביח ינפל הנקתה תוארוה תאחתמ אורקל שי רוקמל תכרעמה רוביח ינפל הנקתה תוארוה תאחתמ 30
لا تاداشرإ رقابيكرت ليصوت لبق ىلإ ماظنلا ةقاطلل ردصم 30
A 250vd 31
Circuit breaker 31
Vdc 20 31
متيتلا 31
ىلع 31
يئاقول 31
Power disconnection warning 32
הרהזא למשחה תורוקמ לכמ תכרעמה תא קתנל שי ריסהל שיו קפסהמ ילמשחה לבכ תא נקתה ךרוצל זראמה לש ימינפה קלחל השיג ינפלת רסה ואת םיביכר 33
ילמשח קותינ ינפמ הרהזא 33
مصف بجي واظننا عيمج نمرداصم تقاطنا تنازإو ءابرهكنا كهس نم ةدحو دادما تقاطنا مبق ىنإ لىصىنا تيهخادنا قطانمنا نمكيهه تنازإ وأ جيبثتن ثانىكم زاهجلا 33
Equipment installation 34
הרהזא שר דבלב ךמסומ תווצתא ףילחהל ןיקתהל יא דויצה רובע תוריש תתל וא דויצה 34
هيبردملاو و بيكزتللادبتسا وأ ةمدخ ساهجلا اذه حمسي نأ بجي طقف هيلهؤملا هيفظىملل 34
Restricted area 35
Battery handling 36
תלבגומ השיג םע רוזא הרהזא תרזעב תנתינ השיגה השיג תלבגה םהב שיש םירוזאב הדיחיה תא ןיקתהל שי דכו לוענמ חתפמ דבלב החטבא ילכ 36
صيصخت ةذحىنا هذه ف اهب كرتن قطانم ةروظحم مت صىنا نكم نإ لى تقطنم ةروظحم طقف واذختسا للاخ نم تصاخ ةادأ وأ أ لان يرخأ ته سو املأم حاتفمو مفق 36
הרהזא תנכס תמייקץוציפ הניקת אל ךרדב הפלחוהו הדימב הללוסה לש ףילחהל שי גוסב הללוסה תא מ םאותה תרבחלמומ ןרציתצ תוללוסה קוליס תושמושמה עצבל שי ןרציה תוארוה יפל 37
رطخ كانه نم لاذبحسا ةلاح يف راجفنا ةيراطبلا ةحيحص ريغ ةقيرطب ليلعف ةيراطبلا لاذبحسا طقف عىنلا سفنب اهلداعي ام وأ اممثصوأ ةعنصملا ةمرشلا هب تايراطبلا نم صلخج ل اقفو ةلمعحسملاةعناصلا ةمرشلا تاميلعح 37
Redundant power supplies 38
דחא קפסמ רתוי םייק םא הרהזא קפס לש דחא רוביחמ רתוי שי הדחיל תא ריסהל שי ןקורל תנמ לע םירוביחה לכ 38
חיה תאי הד 38
Backplane voltage 39
دق اذهل نوكي لازاهج تلااصتا ةدع تادحوب ةقاطلا دادما ةلازإ بجي تلااصتلاا ةفاك لسعل لاةدحو نع ءابرهكلا 39
Comply with local and national electrical codes 40
ירוחאה לנפב חתמ זא הרה ךלהמב רהזיהל שי תכרעמה לועפת ןמזב ירוחאה לנפב חתמ תנכס תמייק הדובעה 40
كانه زطخ هم يئابزهكلا رايتلا ىلع ةدىجىملا ةقاطلاوأ ةحىللا نىكي امدنعماظنلا لمعي دنع ارذح هك ةمدخ ساهجلا اذه 40
Product disposal 41
יצראה למשחה יקוח םואית הרהזא תנקתה םייצראהו םיימוקמה למשחה יקוחל תמאות תויהל תבייח דויצה 41
تادعملا بيكرت ةيئابرهكلا لل لثتمي نأ بجي هيواىقةيىطىلاو ةيلحملا ةقلعتملا ءابرهكلاب 41
Hot swap fan warning 42
רצומה קוליס הרהזא ו תויחנהל םאתהב תויהל בייח הז רצומ לש יפוס קוליס הנידמה יקוח 42
يئاهنلا صلختلا نم جتنملا اذه هعم لماعتلا يغبني ل اقفو عيمجةينطىلا حئاىللاو نيناىقلا دنع 42
הרהזא יקלח תא םיריסמ רשאכ שי םידבוע ןיידע םיררוואמהו ןכתי זראמהמ ררוואמה קיחרהללררוואמה ךותב םיחתפהמ םינוש הדובע ילכו תועבצאה תא חוטב קחרמ 43
عباصلأا ويغاربنا تاكفم ءايشلأا هم اهريغو اديعب هع تاحتفنا يف ةهتك ةحورمنا 43
هكممنا هم حوارمنا نأ لاست لا ةنازإ دنعرودت ةهتك ةحورمنا مكيهنا هم بجي ءاقبإ هكممنا هم حوارمنا نأ لاست لا ةنازإ دنعرودت ةهتك ةحورمنا مكيهنا هم بجي ءاقبإ 43
Power cable and ac adapter 44
1 handling the motherboard 47
Advanced motherboard setup 47
Chapter 5 47
Precautions 47
2 processor and heatsink installation 48
Installing an lga 1150 processor 48
Cpu pin 1 49
Installing a passive cpu heatsink 50
Removing the heatsink 50
Chapter 5 advanced motherboard setup 51
Figure 5 1 installing the heatsink 51
Figure 5 2 removing the heatsink 51
3 connecting cables 53
Connecting data cables 53
Connecting power cables 53
Connecting the control panel 53
4 i o ports 54
5 installing memory 55
Align the key on the dimm module with the receptive point on the slot 55
Caution 55
Chapter 5 advanced motherboard setup 55
Dimma1 55
Exercise extreme care when installing or removing dimm modules 55
Figure 5 3 installing dimm into slot 55
Front view 55
Insert the desired number of dimms into the memory slots starting with slot 55
Installing dimms 55
Into the slot until the module snaps into place 55
Memory support 55
Note check the supermicro web site for recommended memory modules 55
Press the release tabs to the lock positions to secure the dimm module into 55
Push the release tabs outwards on both ends of the dimm slot to unlock it 55
The slot see figure 5 3 55
The x10sll f supports up to 32 gb of unbuffered ecc ddr3 1600 1333 memory populating these dimm modules with a pair of memory modules of the same type and same size will result in interleaved memory which will improve memory per formance 55
To prevent any possible damage 55
Top view of ddr3 slot 55
Use two thumbs together to press on both ends of the module straight down 55
Chapter 5 advanced motherboard setup 57
Possible system memory allocation availability 57
6 adding pci cards 58
7 motherboard details 59
X10sll f quick reference 59
X10slm f x10sll f sf s 59
8 connector definitions 61
Chapter 5 advanced motherboard setup 61
Hdd led 61
Nmi button 61
Power connectors 61
Power led 61
The 24 pin main power connector jpw1 is used to provide power to the motherboard the 8 pin cpu power connector jpw2 is also required for the processor these power connectors meet the ssi eps 12v specification see the tables on the right for pin definitions 61
The hdd led connections are located on pins 13 and 14 of jf1 attach a cable here to indicate hdd activity see the table on the right for pin definitions 61
The non maskable interrupt button header is located on pins 19 and 20 of jf1 refer to the table on the right for pin definitions 61
The power led connection is located on pins 15 and 16 of jf1 refer to the table on the right for pin definitions 61
Connect an led cable to the front uid and oh fan fail connections on pins 7 and 8 of jf1 to display uid unit id sig nals or to provide advanced warnings for chassis overheat fan failure refer to the table on the right for pin definitions 62
Erver 5018d mf user s manual 62
Nic1 nic2 lan1 lan2 62
On the right for pin definitions 62
Overheat oh fan fail front uid led 62
Power fail led 62
Reset button 62
Serial ports 62
The com1 port is located on the i o backpanel com2 is a header located on the the motherboard see the table 62
The nic network interface controller led connection for lan port 1 is located on pins 11 and 12 of jf1 and the led connection for lan port 2 is on pins 9 and 10 attach nic led cables to nic1 led and nic2 led to display network activities for lan 1 and lan2 refer to the table on the right for pin definitions 62
The power fail led connection is located on pins 5 and 6 of jf1 refer to the table on the right for pin definitions 62
The reset button connection is located on pins 3 and 4 of jf1 attach it to a the hardware reset button on the computer case refer to the table on the right for pin definitions 62
Chapter 5 advanced motherboard setup 63
Four universal serial bus 2 ports usb 4 5 6 7 are located on the i o back panel of the x10sll f in addition two usb 3 headers usb 0 1 are located on the x10sll f see the tables below for pin definitions 63
Power button 63
The power button connection is located on pins 1 and 2 of jf1 momentarily contacting both pins will power on off the system this button can also be config ured to function as a suspend button see bios setup to turn off the power in the suspend mode press the button for at least 4 seconds refer to the table on the right for pin definitions 63
Universal serial bus usb 63
A chassis intrusion header is located at jl1 on the motherboard attach the ap propriate cable from the chassis to inform you of a chassis intrusion when the chas sis is opened 64
Chassis intrusion 64
Erver 5018d mf user s manual 64
Fan headers 64
For pin definitions please note that the speaker connector pins 4 7 are used with an external speaker if you wish to use the onboard speaker you should close pins 6 7 with a jumper 64
Internal buzzer sp1 64
On the jd1 header pins 1 3 are used for power led indication and pins 4 7 are for the speaker see the tables on the right 64
Power led speaker 64
The internal buzzer sp1 can be used to provide audible indications for various beep codes see the table on the right for pin definitions 64
The x10sll f has five fan headers fan1 fan4 and fana these are 4 pin fan headers and work with ipmi to moni tor and change fan speed as required based on the system temperature refer to the table on the right for pin definitions 64
A system management bus header for the ipmi slot is located at ipmb con nect the appropriate cable here to use the ipmb i2c connection on your system 65
C connector 65
C connector is located at jp 65
C on the motherboard this connector monitors the status of the power supply fan and system tempera ture see the table on the right for pin definitions 65
Chapter 5 advanced motherboard setup 65
Power supply 65
System management bus jipmb 65
The power supply 65
The wake on lan header is located at jstby1 on the motherboard see the table on the right for pin definitions you must also have a lan card with a wake on lan connector and cable to use this feature 65
This header is used to connect a trusted platform module tpm available sepa rately from a third party vendor a tpm is a security device that allows encryption and authentication of hard drives disal lowing access if the tpm associated with it is not installed in the system see the table on the right for pin definitions 65
Trusted platform module header 65
Wake on lan 65
Dom pwr connector 66
Erver 5018d mf user s manual 66
Pose input output headers are provided on the motherboard these headers are used to communicate with the enclosure management chip in the system see the table on the right for pin definitions 66
T sgpio 1 2 3 sgpio 1 2 headers 66
The disk on module dom power con nector located at jsd1 provides 5v gen1 gen power to a solid state dom storage device connected to one of the sata ports see the table on the right for pin definitions 66
Two t sgpio serial link general pur 66
9 jumper settings 67
10 onboard indicators 70
11 sata drive connections 71
Chapter 5 advanced motherboard setup 71
Sata ports 71
Two sata 3 and four sata 2 ports are included on the motherboard see the table on the right for pin definitions for the onboard sata ports 71
12 installing software 72
Superdoctor 5 73
13 onboard battery 74
1 static sensitive devices 75
Advanced chassis setup 75
Chapter 6 75
Precautions 75
2 control panel 76
Unpacking 76
3 system fans 77
System fan failure 77
4 drive bay installation removal 78
Accessing the drive bays 78
Dvd rom drive installation 79
5 power supply 81
Power supply failure 81
1 introduction 83
Chapter 7 83
How to change the configuration data 83
Starting bios setup utility 83
2 main setup 84
How to start the setup utility 84
3 advanced setup configurations 86
Boot feature 86
Power configuration 87
Cpu configuration 88
Chipset configuration 93
Pci e configuration 93
System agent sa configuration 93
Memory configuration 94
Pch io configuration 95
Sata configuration 97
Pcie pci pnp configuration 98
Acpi settings 100
Intel server platform services configuration 100
Super io configuration 101
Console redirection settings 102
Console redirection settings for ems 104
4 event logs 105
Change smbios event log settings 105
View smbios event log 106
The following ipmi information will be displayed 107
Bmc network configuration 108
5 boot settings 109
6 security settings 111
7 save exit 112
Appendix a 115
Bios error beep codes 115
Appendix b 117
Chassis 117
Chipset 117
Expansion slots 117
Memory capacity 117
Motherboard 117
Processors 117
Sata controller 117
Sata drive bays 117
System specifications 117
Operating environment 118
Power supply 118
Regulatory compliance 118
System cooling 118
System input requirements 118
Weight 118
Appendix b system specifications 119
