5. ROUTER DESIGN
5. Router design
5.1 Router versions
XR5i v2 router is supplied in the following versions:
Box I/O USB PORT1 PORT2 ETH
XR5i v2F Plastic
XR5i v2F SL Metal
Table 1: Router versions
Figure 2: Front panel XR5i v2F Figure 3: Front panel XR5i v2F SL
5.2 Delivery identification
Trade name Type name Other
XR5i v2F XR-5i-v2 Full version
XR5i v2F SL XR-5i-v2 Full version in the metal box
Table 2: Delivery identification
Figure 4: Label XR5i v2F
Figure 5: Label XR5i v2F SL
5
