CONEL XR5i v2E [12/35] Ordering codes

5. ROUTER DESIGN

5.3 Ordering codes

Expansion port Possible participation Ordering code

Version without expansion port XR5i v2F set

Version with Ethernet expansion port PORT1 XR5i v2F ETH set

Version with RS232 expansion port PORT1 a PORT2 XR5i v2F RS232 set

Version with RS485 expansion port PORT1 a PORT2 XR5i v2F RS458 set

Version with MBUS expansion port PORT1 a PORT2 XR5i v2F MBUS set

Version with CNT expansion port PORT1 XR5i v2F CNT set

Version with WIFI expansion port PORT2 XR5i v2F WIFI set

Version with WMBUS expansion port PORT2 XR5i v2F WMBUS set

Version with SDH expansion port PORT2 XR5i v2F SDH set

Table 3: Ordering codes

Second expansion port is written after ﬁrst expansion port in the ordering code.

Example:

• Full version with Ethernet and RS232 port: XR5i v2F ETH RS232 set.

• Full version with Ethernet and RS232 port in metal cover:

XR5i v2F ETH RS232 SL set.
