AT Commands Reference Guide
80000ST10025a Rev. 24 – 2016-09-07
Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 202 of 717
Mod. 0809 2011-07 Rev.2
3.5.5. 3GPP TS 27.005 AT Commands for SMS and CBS
3.5.5.1. General Configuration
3.5.5.1.1. Select Message Service - +CSMS
+CSMS - Select Message Service
SELINT 0 / 1
AT+CSMS
[=<service>]
Set command selects messaging service <service>. It returns the types of messages
supported by the ME:
Parameter:
<service>
0 - The syntax of SMS AT commands is compatible with GSM 27.005
(factory
default)
Set command returns current service setting along with the types of messages
supported by the ME:
+CSMS: <service>,<mt>,<mo>,<bm>
where:
<mt> - mobile terminated messages support
0 - type not supported
1 - type supported
<mo> - mobile originated messages support
0 - type not supported
1 - type supported
<bm> - broadcast type messages support
0 - type not supported
1 - type supported
Note: If parameter is omitted then the behavior of Set command is the same as Read
command.
AT+CSMS?
Read command reports current service setting along with supported message types
in the format:
+CSMS: <service>,<mt>,<mo>,<bm>
where:
<service> - messaging service (see above)
<mt> - mobile terminated messages support (see above)
<mo> - mobile originated messages support (see above)
<bm> - broadcast type messages support (see above)
AT+CSMS=?
Test command reports a list of all services supported by the device. The supported
value of the parameter <service>.
Reference
GSM 27.005; 3GPP TS 23.040; 3GPP TS 23.041
