18
18
Index
Contents
Index
Contents
CONTROL PANEL OVERVIEW
Use the Pen Tablet control panel to customize your Bamboo One pen and tablet.
Experiment with different settings to find what works best for you. Any changes you make will take effect
immediately. Click D
EFAULT to return a tab to the factory settings.
Tool Tips are available for most control panel items. Simply position the screen cursor over an item and let it
rest there; in a few moments the Tool Tip will pop up.
Your keyboard tab and arrow keys can be used to navigate the control panel.
CONTROL PANEL SETTINGS
The following sections provide detailed information about the control panel. They also contain useful
customizing tips.
Customizing the pen
Tablet tracking
Displays customizable
settings.
Displays information
about the control
panel and driver.
Displays this User’s Manual.
Resets the tab to its
default settings.
Closes the control
panel.
