BUTTON FUNCTIONS
The following options are available for your pen button settings.
CLICK. Default setting for the pen tip. This option simulates a primary
mouse button click.
DOUBLE CLICK. Simulates a double-click. For easier double-clicking, use
this function instead of tapping twice with the tip of your pen.
MIDDLE CLICK. Simulates a middle mouse button click.
RIGHT CLICK. Simulates a right mouse button click, which displays a context
menu.
CLICK LOCK. Simulates holding down the primary mouse button. Press the
tool button once to initiate click lock. Press the button again to release click
lock. Click lock is useful for dragging objects or selecting blocks of text.
BACK. Simulates a 4th mouse button click, which typically issues the BACK
command in browser applications.
FORWARD. Simulates a 5th mouse button click, which typically issues the
FORWARD command in browser applications.
PAN/SCROLL. Enables you to move a document or image in any direction
within the active window using your Bamboo One pen.
INK TOGGLE. (Macintosh.) Toggles the INK ANYWHERE function of Inkwell on
and off. Inkwell automatically recognizes and converts your handwriting into
text and inserts it into a document. Note that Ink must be turned on for this
function to work. See your Macintosh help for information on working with
Inkwell.
