Yealink W52P IP DECT Phones Auto Provisioning Guide
32
The following lists the processes for triggering auto provisioning via activation code:
1. Create multiple directories (e.g., two directories) on the provisioning server.
2. Store a common CFG file and multiple <MAC>.cfg files to each directory on the
provisioning server.
3. Configure a user name and password for each directory.
The user name and password provides a means of conveniently partitioning the
configuration files for different base stations. To access the specified directory, you
need to provide the correct user name and password configured for the directory.
4. Configure unique activation codes and the provisioning server URLs on IP phones.
The activation code can be numeric string and special characters “*”, ”#” with a
maximum of 24 characters.
The following are example configurations in the configuration file for IP phones:
autoprovision.1.code = *123
autoprovision.1.url = tftp://192.168.1.30/W52P_1/
autoprovision.2.code = *456
autoprovision.2.url = tftp://192.168.1.30/W52P_2/
5. Send the IP phone, specified activation code and associated user name and
password to each end-user.
6. Set up the IP phone, and then dial the activation code after phone startup to trigger
the IP phone to perform auto provisioning.
The LCD screen will prompt for the user name and password.
7. Enter the user name and password.
The entered user name and password must be correspond to the directory where
the configuration files of the IP phone are located. If you enter invalid user name or
password, the LCD screen will prompt the message “Wrong user name or
password!”. The prompt message will disappear in two seconds, and the LCD
screen will return to the idle screen. You need to dial out the activation code again
to trigger the auto provisioning process.
The IP phone downloads the y000000000025.cfg and the corresponding <MAC>.cfg
files from the provisioning server to complete phone configurations.
The entered user name and password will be saved to the IP phone for next auto
provisioning via activation code and auto provisioning via update modes.
The LCD screen will not prompt for user name and password if the provisioning server
does not require authentication, or the user name and password are already saved on
the IP phone.
If more than one handset registered on the same base station triggers the auto
provisioning process via the activation code simultaneously, the base station will perform
the auto provisioning process when any handset enters the correct user name and
password.
