VC110 Video Conferencing Endpoint Introduction
9
Infrared Sensor
The infrared sensor is located within the Yealink logo. Aim the remote control at the
camera IR sensor to operate the unit.
Note
The right side of the VC110 all-in-one unit
Port Name
Description
①
USB
Inserts a USB flash drive to one of the two USB ports
for storing screenshots and recording videos.
Inserts a dongle to one of the two USB ports for
connecting the VCM60 video conferencing wireless
microphone.
Note:
The wireless microphone dongle and USB flash
drive can work at the same time.
If two USB flash drives are connected, only the
latter one can be identified.
When the endpoint is powered on, avoid physically turning the camera. This may cause
permanent damage to the camera. Always use the remote control to pan and tilt it.
