Administrator‘s Guide for Yealink VC110 Video Conferencing Endpoint
212
You can enter the view call statistics screen during an active call. Information includes:
Total Bandwidth: Uplink Bandwidth and Downlink Bandwidth.
Video: Resolution, Codec, Bandwidth, Frame Rate, Jitter, Total Packet Lost, Packet
Lost(%).
Protocol used during a call.
Device information of the far site.
Audio: Codec, Bandwidth, Sample Rate, Jitter, Total Packet Lost, Packet Lost(%)
Share: Resolution, Codec, Bandwidth, Frame Rate.
Use the remote control to select More->Call Statistics during an active call to view call
statistics.
The endpoint supports the following diagnostic methods:
Audio Diagnose: Check whether the audio input device and audio output device
are working properly.
Camera Diagnose: Check whether the camera can pan and change focus
normally.
Ping: Check whether the endpoint can establish contact with the IP address that
you specify.
Trace Route: Display the route (path) and measure transit delays of packets across
an Internet Protocol (IP) network.
To diagnose audio via the remote control:
1. Select Menu->Diagnose menu.
2. Select Audio Diagnose, and then press .
3. Speak into the microphone.
4. Check whether the microphone can pick up audio and play back the audio
properly.
If the endpoint plays back the audio normally, it means that audio works well.
5. Press to stop audio diagnostics.
To diagnose the camera via the remote control:
1. Select Menu->Diagnose menu.
2. Select Camera Diagnose, and then press .
3. Press navigation keys to adjust the camera position.
