Yamaha NS-777, пара [2/6] Procedure

When placing the speakers, be sure to use the stands to

increase stability.

Note

The provided stands are in two types. Two stands are for the right

side and others are for the left side. Attach each stand to the proper

position on the bottom of the speaker by following the figure

below.

Use the 8 specified holes located on the base of the speaker.

Procedure:

1 First, put the screw through the washer, then through

the inner hole of the stand, and screw it into the outside

hole of the speaker. Do not tighten too much at this

point.

2 Put a screw through the outer hole on the stand, and

screw it into the other hole on the base of the speaker.

3 Tighten both of the screws firmly.

4 Attach a pad to the bottom of the end portion of the

stand.

5 Attach the other stands to the other corners of the base

of the speaker in the same way and confirm that all 4

stands have been firmly attached.

Note

Be carefull not to apply force to the side of the speaker, otherwise

the speaker may fall causing damage to the speaker or personal

injury.

ATTACHING THE STANDS

(L) (R)

Stand (R x 2, L x 2)

Pad x 4

Washer x 4

Screw

(25mm) x 8

Back

(L)

(R)

(L)

Front

View from the bottom of the speaker

Outer hole

Inner hole
