Yamaha NS-777, пара [6/6] 卸下前盖
![Yamaha NS-777, пара [6/6] 卸下前盖](/views2/1192396/page6/bg6.png)
5
前盖四周六点被扣紧，可根据需要卸下。卸下前盖时，
握住两边从扬声器慢慢直拉出来。如需再安装，将前
盖里层的六个钉对准扬声器六个相应的孔，轻轻推
入。
注意
当前盖被卸下后，切勿用手接触扬声器或用工具过分
施力。
NS-777
种类................................ 3 声道低频反射式扬声器系统
磁屏型
驱动器................................. 20 cm 圆锥低音扬声器× 2
波导喇叭 13 cm 圆锥中型
波导喇叭 2.5 cm 穹型低音扬声器
频率响应................................................ 30 Hz 至 35 kHz
额定阻抗................................................................ 6 欧姆
额定输入功率.........................................................100 W
最大输入功率.........................................................250 W
敏感度......................................................89 dB/2.83 V/m
交换频率.................................................... 1 kHz， 4 kHz
尺寸 ( 宽×高×深 )
........276 mm
×
1100 mm
×
390 mm
重量....................................................................... 24.4 kg
附件.......................................... 支架 ( 右× 2，左× 2)
垫圈× 4
螺丝× 8
防滑垫× 4
NS-555
种类................................ 3 声道低频反射式扬声器系统
磁屏型
驱动器................................. 16 cm 圆锥低音扬声器× 2
波导喇叭 13 cm 圆锥中型
波导喇叭 2.5 cm 穹型低音扬声器
频率响应................................................ 35 Hz 至 35 kHz
额定阻抗................................................................ 6 欧姆
额定输入功率.........................................................100 W
最大输入功率.........................................................250 W
敏感度......................................................88 dB/2.83 V/m
交换频率.................................................... 1 kHz， 4 kHz
尺寸 ( 宽×高×深 )....222 mm × 980 mm × 345 mm
重量.......................................................................... 20 kg
附件.......................................... 支架 ( 右× 2，左× 2)
垫圈× 4
螺丝× 8
防滑垫× 4
· 产品规格若有变动，恕不另行通知。
· 请注意输入功率值不要超过上述值。
卸下前盖
NS-777
NS-555
规格
NS-777_555_c.fm Page 5 Wednesday, March 12, 2003 11:21 AM
