TA1600/2400/3200 User Manual
12/66
Static IP Address
PPPoE
Here we introduce how to set a static IP address for TA1600/2400/3200.
IP address: 192.168.10.125
Subnet mask: 255.255.255.0
Gateway: 192.168.10.1
DNS: 8.8.8.8
1. Press *** to enter the voice menu.
2. Press 3 to enter the ―Advanced Settings‖.
3. Enter the password follow by the pound key: 123456# (The default password is
123456).
4. Press 2 to change the IP address.
5. Press 2 to enable the static IP.
6. Press 1 to change the IP address and follow by the new IP address
(1192*168*10*125).
7. Press 2 to change the subnet mask and follow by the new subnet mask
(2255*255*255*0).
8. Press 3 to change the gateway and follow by the new gateway (3192*168*10*1).
9. Press 4 to change the DNS and followed by the new DNS (48*8*8*8).
10. Press 5 to reboot the device.
11. After reboot, you can access the device by the new IP address.
