TA1600/2400/3200 User Manual
38/66
configure the tone zone settings on TA FXS Gateway:
http://www.itu.int/ITU-T/inr/forms/files/tones-0203.pdf
Figure 8-3 Customize Tones
Table 8-1 Description of Tone Zone Settings
Items
Description
Country/Region
Choose the country to get pre-programmed tone zone settings or
choose "User custom for Tone Zone" to configure the settings
manually.
Ring Cadence
Configuration option for all FXS ports ring cadence for all
incoming calls.
Dial Tone
Prompt tone of off-hook dial tone.
Ringback Tone
The tone sent to caller when ringing is on.
Busy Tone
Used for busy line prompt.
Call-Waiting Tone
Used for notification in call waiting.
Congestion Tone
Used to indicate that an invalid code has been dialed, or that all
circuits (trunks) are busy and/or the call is unroutable.
2nd Dial Tone
Used for the second stage dial tone.
Message Tone
Used for message tone.
VoiceMail Tone
Used for voicemail tone.
RADIUS Settings
TA FXS Gatewaysupports RADIUS (Remote Authentication Dial In UserService)
protocol. RADIUS feature is mainly for billing purpose on TA FXS Gateway. There
areprimary and secondary RADIUS server configurations available. Once the primary
server is unreachale, the RADIUS requests will be sent to the secondary server.
